Dayton 11.75"H-W 3.7"L Square GStl Fire Dampr: Dynamic, 11 3/4 in H, 11 3/4 in W - Rectangular Fire Dampers
DaytonRectangular Fire Dampers

Dayton 11.75"H-W 3.7"L Square GStl Fire Dampr: Dynamic, 11 3/4 in H, 11 3/4 in W

The Dayton 2TGF4 is a rectangular fire damper with a square profile, measuring 11.75 inches in height and width and 3.7 inches in length. It features a curtain blade type and a spring closure mechanism, designed for…

SKU 3G-OTH-74198

Brand
Dayton
Item
11.75"H-W 3.7"L Square GStl Fire Dampr: Dynamic, 11 3/4 in H, 11 3/4 in W
Category
Rectangular Fire Dampers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
2TGF4
Type
11 3/4 in W, 3 3/4 in L, Spring
H
11 3/4 in
Blade Type
Curtain
Closure Type
Spring
Mounting Position
Vertical
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 2TGF4 is a rectangular fire damper with a square profile, measuring 11.75 inches in height and width and 3.7 inches in length. It features a curtain blade type and a spring closure mechanism, designed for vertical mounting positions.

Frequently Asked Questions

What is the Dayton 2TGF4 fire damper used for?

The Dayton 2TGF4 is a rectangular fire damper used in HVAC systems to prevent fire and smoke spread through ductwork. Its spring-closure curtain blade activates automatically when a fusible link melts, sealing the duct. It is designed for vertical mounting in commercial or industrial buildings.

What are the specifications of the Dayton 2TGF4 fire damper?

The Dayton 2TGF4 has a square profile measuring 11 3/4 in H, 11 3/4 in W, and 3 3/4 in L. It features a curtain blade type with a spring closure mechanism and is designed for vertical mounting. The manufacturer part number is 2TGF4.

Where to buy the Dayton 2TGF4 fire damper worldwide?

3G Electric supplies the Dayton 2TGF4 fire damper to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this and other HVAC safety components.

How to install a Dayton 2TGF4 fire damper?

Install the Dayton 2TGF4 in a vertical duct opening, ensuring the damper frame is securely fastened per local codes. The spring closure mechanism requires a fusible link rated for the application temperature. Always follow NFPA guidelines and the manufacturer's instructions for proper operation and testing.
