Dayton 15.75"H 11.75"W 3.7"L GStl Fire Dampr: Dynamic, 11 3/4 in H, 15 3/4 in W - Rectangular Fire Dampers
DaytonRectangular Fire Dampers

Dayton 15.75"H 11.75"W 3.7"L GStl Fire Dampr: Dynamic, 11 3/4 in H, 15 3/4 in W

The Dayton 2TGF8 is a rectangular fire damper with a curtain blade type and spring closure, designed for horizontal mounting. It measures 15.75 inches in height, 11.75 inches in width, and 3.7 inches in length…

SKU 3G-OTH-74485

Brand
Dayton
Item
15.75"H 11.75"W 3.7"L GStl Fire Dampr: Dynamic, 11 3/4 in H, 15 3/4 in W
Category
Rectangular Fire Dampers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
2TGF8
Type
15 3/4 in W, 3 3/4 in L, Spring
H
11 3/4 in
Blade Type
Curtain
Closure Type
Spring
Mounting Position
Horizontal
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 2TGF8 is a rectangular fire damper with a curtain blade type and spring closure, designed for horizontal mounting. It measures 15.75 inches in height, 11.75 inches in width, and 3.7 inches in length, constructed from galvanized steel.

Frequently Asked Questions

What is the Dayton 2TGF8 fire damper used for?

The Dayton 2TGF8 is a rectangular fire damper used in HVAC systems to prevent fire and smoke spread through ductwork. It is designed for horizontal mounting in commercial or industrial buildings, with a curtain blade and spring closure that automatically seals the duct when triggered by heat.

What are the specifications of the Dayton 2TGF8 fire damper?

The Dayton 2TGF8 measures 15.75 inches in height, 11.75 inches in width, and 3.7 inches in length. It features a curtain blade type, spring closure, and is designed for horizontal mounting. The damper is constructed from galvanized steel and is manufactured by Dayton under part number 2TGF8.

Where to buy the Dayton 2TGF8 fire damper worldwide?

You can source the Dayton 2TGF8 fire damper through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine Dayton components for HVAC fire safety applications.

How to install the Dayton 2TGF8 fire damper?

Install the Dayton 2TGF8 horizontally in ductwork, ensuring the curtain blade moves freely and the spring closure is unobstructed. Secure the damper frame to the duct with appropriate fasteners, and verify that the fusible link or actuator is correctly positioned. Follow local fire codes and manufacturer guidelines for safe operation.
