Dayton Pillow Block Bearing: 1 3/16 in Bore, Cast Iron, Set Screws, 1 11/16 in Shaft Ht - General Purpose Pillow Block Ball Bearings
DaytonGeneral Purpose Pillow Block Ball Bearings

Dayton Pillow Block Bearing: 1 3/16 in Bore, Cast Iron, Set Screws, 1 11/16 in Shaft Ht

The DAYTON 3FDA1 is a general purpose pillow block ball bearing with a 1 3/16 in bore, featuring a cast iron housing and set screw locking. It has a 1 11/16 in shaft height and a mounting bolt size of 1/2 in…

SKU 3G-OTH-104895

Brand
Dayton
Item
Pillow Block Bearing: 1 3/16 in Bore, Cast Iron, Set Screws, 1 11/16 in Shaft Ht
Category
General Purpose Pillow Block Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
3FDA1
Type
Cast Iron, Set Screws, 3FDA1
Shaft Ht
1 11/16 in
Mounting Bolt Size
1/2 in
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON 3FDA1 is a general purpose pillow block ball bearing with a 1 3/16 in bore, featuring a cast iron housing and set screw locking. It has a 1 11/16 in shaft height and a mounting bolt size of 1/2 in, designed for inch-system applications.

Frequently Asked Questions

What is the DAYTON 3FDA1 pillow block bearing used for?

The DAYTON 3FDA1 is a general purpose pillow block ball bearing used to support rotating shafts in industrial machinery. Its cast iron housing and set screw locking suit moderate-load applications like conveyors, fans, and agricultural equipment, where inch-system mounting is required.

What are the specifications of the DAYTON 3FDA1 pillow block bearing?

The DAYTON 3FDA1 has a 1 3/16 in bore, 1 11/16 in shaft height, and 1/2 in mounting bolt size. It features a cast iron housing with set screw locking and is designed for inch-system applications. The manufacturer part number is 3FDA1.

Where to buy the DAYTON 3FDA1 pillow block bearing worldwide?

3G Electric supplies the DAYTON 3FDA1 pillow block bearing worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this inch-system bearing.

How to install the DAYTON 3FDA1 pillow block bearing?

To install the DAYTON 3FDA1, align the bearing on a flat surface, tighten the mounting bolts to the specified torque, and secure the shaft using the set screws. Ensure proper lubrication before operation. Follow generic pillow block installation best practices for optimal performance.
