Dayton Pillow Block Bearing: 5/8 in Bore, Cast Iron, Set Screws, 1 5/16 in Shaft Ht - General Purpose Pillow Block Ball Bearings
DaytonGeneral Purpose Pillow Block Ball Bearings

Dayton Pillow Block Bearing: 5/8 in Bore, Cast Iron, Set Screws, 1 5/16 in Shaft Ht

The DAYTON Pillow Block Bearing (SKU 3FDA3) is a general purpose pillow block ball bearing with a 5/8 in bore, designed for inch-system applications. It features a cast iron housing, set screw locking, a 1 5/16 in…

SKU 3G-OTH-108016

Brand
Dayton
Item
Pillow Block Bearing: 5/8 in Bore, Cast Iron, Set Screws, 1 5/16 in Shaft Ht
Category
General Purpose Pillow Block Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
3FDA3
Type
Cast Iron, Set Screws
Overall Lg
5 in
Shaft Ht
1 5/16 in
Mounting Bolt Size
3/8 in
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Pillow Block Bearing (SKU 3FDA3) is a general purpose pillow block ball bearing with a 5/8 in bore, designed for inch-system applications. It features a cast iron housing, set screw locking, a 1 5/16 in shaft height, and a 5 in overall length. The mounting bolt size is 3/8 in.

Frequently Asked Questions

What is the DAYTON Pillow Block Bearing 3FDA3 used for?

The DAYTON Pillow Block Bearing 3FDA3 supports rotating shafts in industrial machinery, conveyors, and material handling equipment. Its cast iron housing and set screw locking suit moderate-load, inch-system applications where reliable shaft alignment and easy mounting are needed.

What are the specifications of the DAYTON Pillow Block Bearing 3FDA3?

The DAYTON Pillow Block Bearing 3FDA3 has a 5/8 in bore, cast iron housing, set screw locking, 1 5/16 in shaft height, and 5 in overall length. Mounting bolt size is 3/8 in. It is an inch-system general purpose ball bearing for moderate-duty applications.

Where to buy the DAYTON Pillow Block Bearing 3FDA3 worldwide?

3G Electric supplies the DAYTON Pillow Block Bearing 3FDA3 worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this inch-system bearing.

How to install the DAYTON Pillow Block Bearing 3FDA3?

Mount the DAYTON 3FDA3 on a clean, flat surface using 3/8 in bolts through the base slots. Align the shaft with the 5/8 in bore, tighten set screws evenly against the shaft, and verify free rotation. Lubricate per manufacturer guidelines before operation.
