Dayton Exhaust Fan: 20 in Blade - Belt-Drive Panel Exhaust Fans without Drive Package
DaytonBelt-Drive Panel Exhaust Fans without Drive Package

Dayton Exhaust Fan: 20 in Blade

The Dayton 3FKD8 is an unassembled belt-drive panel exhaust fan with a 20-inch blade, designed for air flows from 4,404 to 6,348 cfm depending on the motor. It features a stamped steel frame with a zinc-plated finish…

SKU 3G-OTH-83661

Brand
Dayton
Item
Exhaust Fan: 20 in Blade
Category
Belt-Drive Panel Exhaust Fans without Drive Package
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
3FKD8
Type
For 4,404 cfm to 6,348 cfm Air Flow (Dependent on Motor)
Assembled
Unassembled
Guard Type
None
Frame Finish
Zinc-Plated
Frame Material
Steel
Guard Type Subheads
Without Intake Guards
Method of Construction
Stamped
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 3FKD8 is an unassembled belt-drive panel exhaust fan with a 20-inch blade, designed for air flows from 4,404 to 6,348 cfm depending on the motor. It features a stamped steel frame with a zinc-plated finish and is supplied without intake guards.

Frequently Asked Questions

What is the Dayton 3FKD8 exhaust fan used for?

The Dayton 3FKD8 is a belt-drive panel exhaust fan used for general ventilation in industrial and commercial facilities. It moves 4,404 to 6,348 cfm (dependent on motor) to remove heat, fumes, or stale air from warehouses, factories, and workshops.

What are the specifications of the Dayton 3FKD8 exhaust fan?

The Dayton 3FKD8 has a 20-inch blade, stamped steel frame with zinc-plated finish, and is supplied unassembled without intake guards. Air flow ranges from 4,404 to 6,348 cfm depending on the motor selected. It is a belt-drive panel exhaust fan without drive package.

Where to buy the Dayton 3FKD8 exhaust fan worldwide?

3G Electric supplies the Dayton 3FKD8 exhaust fan to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this unassembled belt-drive fan.

How to install the Dayton 3FKD8 exhaust fan?

The Dayton 3FKD8 is supplied unassembled and requires mounting the stamped steel frame into a wall or panel opening. Install the motor and drive package (not included) per manufacturer instructions. Ensure proper belt tension and alignment for the 20-inch blade to achieve rated cfm.
