Dayton Exhaust Fan: 48 in Blade - Belt-Drive Panel Exhaust Fans without Drive Package
DaytonBelt-Drive Panel Exhaust Fans without Drive Package

Dayton Exhaust Fan: 48 in Blade

The Dayton 1WDC4 is an unassembled belt-drive panel exhaust fan with a 48-inch blade, designed for air flows from 14,214 cfm to 31,442 cfm depending on the motor. It features a stamped steel frame with a zinc-plated…

SKU 3G-OTH-83799

Brand
Dayton
Item
Exhaust Fan: 48 in Blade
Category
Belt-Drive Panel Exhaust Fans without Drive Package
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1WDC4
Type
For 14,214 cfm to 31,442 cfm Air Flow (Dependent on Motor)
Assembled
Unassembled
Guard Type
None
Frame Finish
Zinc-Plated
Frame Material
Steel
Guard Type Subheads
Without Intake Guards
Method of Construction
Stamped
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 1WDC4 is an unassembled belt-drive panel exhaust fan with a 48-inch blade, designed for air flows from 14,214 cfm to 31,442 cfm depending on the motor. It features a stamped steel frame with a zinc-plated finish and is supplied without intake guards. This product is sold without a drive package.

Frequently Asked Questions

What is the Dayton 1WDC4 exhaust fan used for?

The Dayton 1WDC4 is a belt-drive panel exhaust fan for high-volume air movement in industrial facilities, warehouses, and manufacturing plants. It moves 14,214 to 31,442 cfm depending on the motor, helping ventilate heat, fumes, or dust. 3G Electric supplies this fan and handles worldwide delivery.

What are the specifications of the Dayton 1WDC4 exhaust fan?

The Dayton 1WDC4 has a 48-inch blade, stamped steel frame with zinc-plated finish, and is unassembled. It is supplied without intake guards or a drive package. Air flow ranges from 14,214 to 31,442 cfm depending on the motor selected. 3G Electric sources this fan globally.

Where to buy the Dayton 1WDC4 exhaust fan worldwide?

3G Electric supplies the Dayton 1WDC4 exhaust fan to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this belt-drive panel fan.

How to install the Dayton 1WDC4 exhaust fan?

The Dayton 1WDC4 is unassembled and requires mounting the stamped steel frame to a wall or panel, then installing a motor and drive package (not included). Follow standard industrial fan installation practices: secure the frame, align belts, and ensure proper electrical connections. 3G Electric can provide sourcing support.
