Dayton Exhaust Fan: 30 in Blade - Belt-Drive Panel Exhaust Fans without Drive Package
DaytonBelt-Drive Panel Exhaust Fans without Drive Package

Dayton Exhaust Fan: 30 in Blade

The Dayton 1WDC1 is an unassembled belt-drive panel exhaust fan with a 30-inch blade, designed for air flow from 7,096 cfm to 11,061 cfm depending on the motor. It features a stamped steel frame with a zinc-plated…

SKU 3G-OTH-83713

Brand
Dayton
Item
Exhaust Fan: 30 in Blade
Category
Belt-Drive Panel Exhaust Fans without Drive Package
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1WDC1
Type
For 7,096 cfm to 11,061 cfm Air Flow (Dependent on Motor)
Assembled
Unassembled
Guard Type
None
Frame Finish
Zinc-Plated
Frame Material
Steel
Guard Type Subheads
Without Intake Guards
Method of Construction
Stamped
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 1WDC1 is an unassembled belt-drive panel exhaust fan with a 30-inch blade, designed for air flow from 7,096 cfm to 11,061 cfm depending on the motor. It features a stamped steel frame with a zinc-plated finish and is supplied without intake guards.

Frequently Asked Questions

What is the Dayton 1WDC1 exhaust fan used for?

The Dayton 1WDC1 belt-drive panel exhaust fan is used for industrial ventilation, removing heat, fumes, and stale air from factories, warehouses, and commercial facilities. It delivers 7,096 to 11,061 cfm depending on the motor selected, making it suitable for high-volume air movement in large spaces.

What are the specifications of the Dayton 1WDC1 exhaust fan?

The Dayton 1WDC1 has a 30-inch blade, stamped steel frame with zinc-plated finish, and is supplied unassembled without intake guards. Air flow ranges from 7,096 cfm to 11,061 cfm depending on the motor. It is a belt-drive panel exhaust fan without a drive package.

Where to buy the Dayton 1WDC1 exhaust fan worldwide?

You can source the Dayton 1WDC1 exhaust fan through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide competitive sourcing for this Dayton model.

How to install the Dayton 1WDC1 exhaust fan?

Install the Dayton 1WDC1 by mounting the unassembled stamped steel frame securely to a wall or panel opening. Select a compatible motor and drive package (not included) to achieve the desired cfm. Follow standard belt-drive fan installation practices: align pulleys, tension belts, and ensure proper electrical connections per local codes.
