Dayton Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 28 Teeth, 5 mm Pitch - HTD Section Fixed-Bore Timing Pulleys with Hub
DaytonHTD Section Fixed-Bore Timing Pulleys with Hub

Dayton Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 28 Teeth, 5 mm Pitch

The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for use with Powerhouse® belt series. It features 28 teeth, a 5 mm pitch, and accommodates a 9 mm belt width. The…

SKU 3G-OTH-112295

Brand
Dayton
Item
Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 28 Teeth, 5 mm Pitch
Category
HTD Section Fixed-Bore Timing Pulleys with Hub
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
28-5M09M6A8
Type
Fixed, For 9 mm Belt Wd, Aluminum
Pitch
5 mm
Teeth
28
Finish
Clear Anodized
For Belt Series
Powerhouse®
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for use with Powerhouse® belt series. It features 28 teeth, a 5 mm pitch, and accommodates a 9 mm belt width. The pulley is made of aluminum with a clear anodized finish, identified by manufacturer part number 28-5M09M6A8.

Frequently Asked Questions

What is the DAYTON Timing Pulley 28-5M09M6A8 used for?

The DAYTON Timing Pulley is used in synchronous belt drive systems to transmit rotary motion and torque. It is designed for Powerhouse® belt series, commonly applied in industrial machinery, conveyors, and automation equipment requiring precise timing and positioning.

What are the specifications of the DAYTON Timing Pulley 28-5M09M6A8?

This DAYTON Timing Pulley has 28 teeth, a 5 mm pitch, and fits a 9 mm belt width. It is a curvilinear HTD section fixed-bore type with hub, made of aluminum with a clear anodized finish. The manufacturer part number is 28-5M09M6A8.

Where to buy the DAYTON Timing Pulley 28-5M09M6A8 worldwide?

You can source the DAYTON Timing Pulley 28-5M09M6A8 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring reliable supply for your operations.

How to select the correct DAYTON Timing Pulley for a 9 mm belt?

To select the correct DAYTON Timing Pulley, match the belt width (9 mm), pitch (5 mm), and tooth profile (curvilinear HTD). Ensure the bore size fits your shaft and the pulley material (aluminum) suits your environment. The 28-5M09M6A8 is a fixed-bore option with hub for direct mounting.
