Dayton Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 26 Teeth, 3 mm Pitch - HTD Section Fixed-Bore Timing Pulleys with Hub
DaytonHTD Section Fixed-Bore Timing Pulleys with Hub

Dayton Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 26 Teeth, 3 mm Pitch

The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for the Powerhouse® belt series. It features 26 teeth with a 3 mm pitch and accommodates a 9 mm belt width. The…

SKU 3G-OTH-106819

Brand
Dayton
Item
Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 26 Teeth, 3 mm Pitch
Category
HTD Section Fixed-Bore Timing Pulleys with Hub
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
26-3M09M6A6
Type
Fixed, For 9 mm Belt Wd, Aluminum
Pitch
3 mm
Teeth
26
Finish
Clear Anodized
For Belt Series
Powerhouse®
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for the Powerhouse® belt series. It features 26 teeth with a 3 mm pitch and accommodates a 9 mm belt width. The pulley is made of aluminum with a clear anodized finish (MPN 26-3M09M6A6).

Frequently Asked Questions

What is the DAYTON Timing Pulley 26-3M09M6A6 used for?

The DAYTON Timing Pulley is used in synchronous drive systems to transmit rotary motion precisely without slippage. It is designed for the Powerhouse® belt series, commonly applied in industrial machinery, packaging equipment, and automation systems requiring accurate timing and positioning.

What are the specifications of the DAYTON Timing Pulley 26-3M09M6A6?

This DAYTON Timing Pulley is an HTD section fixed-bore pulley with hub, featuring 26 teeth, a 3 mm pitch, and a 9 mm belt width. It is made of aluminum with a clear anodized finish. The manufacturer part number is 26-3M09M6A6, and it is designed for the Powerhouse® belt series.

Where to buy the DAYTON Timing Pulley 26-3M09M6A6 worldwide?

You can source the DAYTON Timing Pulley 26-3M09M6A6 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring you receive the correct component for your drive system.

How to select the correct DAYTON Timing Pulley for a 9 mm belt?

To select the correct DAYTON Timing Pulley, match the belt width (9 mm), pitch (3 mm), and tooth profile (HTD curvilinear). Ensure the pulley bore size fits your shaft and that the pulley is designed for the Powerhouse® belt series. The 26-3M09M6A6 model meets these criteria for fixed-bore applications.
