Dayton 23"H-W 6.5"L Extrd Alu Backdraft Dampr: For 20 in Fan, Single Panel, 23 in H - Wall-Mount Backdraft Dampers
DaytonWall-Mount Backdraft Dampers

Dayton 23"H-W 6.5"L Extrd Alu Backdraft Dampr: For 20 in Fan, Single Panel, 23 in H

The Dayton 4FZH6 is a wall-mount backdraft damper with extruded aluminum flat blades, designed for a 20-inch fan. It features horizontal airflow direction and vertical mounting, with a maximum air velocity of 3250…

SKU 3G-OTH-76326

Brand
Dayton
Item
23"H-W 6.5"L Extrd Alu Backdraft Dampr: For 20 in Fan, Single Panel, 23 in H
Category
Wall-Mount Backdraft Dampers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4FZH6
Type
Single Panel, 23 in W, Wall
D
3 in
H
23 in
Blade Type
Flat Blade
Airflow Direction
Horizontal
Mounting Position
Vertical
Maximum Air Velocity
3250 fpm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 4FZH6 is a wall-mount backdraft damper with extruded aluminum flat blades, designed for a 20-inch fan. It features horizontal airflow direction and vertical mounting, with a maximum air velocity of 3250 fpm. The single-panel unit measures 23 inches high, 23 inches wide, and 3 inches deep.

Frequently Asked Questions

What is the Dayton 4FZH6 backdraft damper used for?

The Dayton 4FZH6 is a wall-mount backdraft damper that prevents reverse airflow when a 20-inch fan is off. It is used in industrial ventilation systems to maintain one-way horizontal airflow, protecting equipment and maintaining air quality in facilities worldwide.

What are the specifications of the Dayton 4FZH6 backdraft damper?

The Dayton 4FZH6 is a single-panel, wall-mount backdraft damper with extruded aluminum flat blades. It measures 23 in H x 23 in W x 3 in D, mounts vertically, handles horizontal airflow, and supports a maximum air velocity of 3250 fpm. It is designed for a 20-inch fan.

Where to buy the Dayton 4FZH6 backdraft damper worldwide?

3G Electric supplies the Dayton 4FZH6 backdraft damper to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and a quote tailored to your location.

How to install the Dayton 4FZH6 backdraft damper?

Install the Dayton 4FZH6 damper vertically on a wall opening matching its 23 in x 23 in dimensions. Ensure the airflow direction arrow points horizontally away from the fan. Secure the frame with appropriate fasteners and seal edges to prevent air leaks. Follow standard industrial damper installation practices.
