Dayton Hydronic Wall and Ceiling Unit Heater: Steam/Water - Suspended Horizontal Hydronic Wall & Ceiling Unit Heaters
DaytonSuspended Horizontal Hydronic Wall & Ceiling Unit Heaters

Dayton Hydronic Wall and Ceiling Unit Heater: Steam/Water

The DAYTON Hydronic Wall and Ceiling Unit Heater (SKU 4NHG5) is a suspended horizontal unit heater designed for water heating, delivering 209,100 BtuH output at 200 °F water and 4,200 cfm air flow. It features a…

SKU 3G-OTH-66171

Brand
Dayton
Item
Hydronic Wall and Ceiling Unit Heater: Steam/Water
Category
Suspended Horizontal Hydronic Wall & Ceiling Unit Heaters
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4NHG5
Type
209,100 BtuH Output @ 200 F Water
Air Flow
4,200 cfm
Fan Guard Type
Standard Guard
Heating Method
Water
Overall Dimensions - H x W x D
30-1/4 in x 27-7/8 in x 17-3/4 in
Connection Size, Connection Type
2 in, Threaded Female NPT
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Hydronic Wall and Ceiling Unit Heater (SKU 4NHG5) is a suspended horizontal unit heater designed for water heating, delivering 209,100 BtuH output at 200 °F water and 4,200 cfm air flow. It features a 2-inch threaded female NPT connection and a standard fan guard, with overall dimensions of 30-1/4 in x 27-7/8 in x 17-3/4 in.

Frequently Asked Questions

What is the DAYTON Hydronic Wall and Ceiling Unit Heater 4NHG5 used for?

The DAYTON 4NHG5 is a suspended horizontal unit heater used for hydronic heating in commercial and industrial spaces. It delivers 209,100 BtuH output at 200 °F water with 4,200 cfm air flow, making it suitable for warehouses, factories, and large open areas requiring reliable water-based heating.

What are the specifications of the DAYTON 4NHG5 unit heater?

The DAYTON 4NHG5 unit heater provides 209,100 BtuH output at 200 °F water, 4,200 cfm air flow, and a 2-inch threaded female NPT connection. It measures 30-1/4 in x 27-7/8 in x 17-3/4 in, uses water as the heating method, and includes a standard fan guard.

Where to buy the DAYTON 4NHG5 unit heater worldwide?

3G Electric supplies the DAYTON 4NHG5 unit heater worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this hydronic heater.

How to install a DAYTON hydronic unit heater like the 4NHG5?

Install the DAYTON 4NHG5 suspended horizontally using threaded 2-inch NPT connections for water supply and return. Ensure proper clearance for airflow and secure mounting to structural supports. Follow local codes and the manufacturer's manual for electrical and piping connections.
