Dayton Manifold Gauge Set: 2 Valves, 3 Hoses, 3 1/8 in Gauge - Analog Manifold Gauge Kits
DaytonAnalog Manifold Gauge Kits

Dayton Manifold Gauge Set: 2 Valves, 3 Hoses, 3 1/8 in Gauge

The DAYTON Manifold Gauge Set (MPN 4PDG1) is an analog manifold gauge kit with 2 valves and 3 hoses, featuring 3 1/8 in gauges. It is designed for use with refrigerants R-22, R-404A, R-407C, and R-410A, with SAE hose…

SKU 3G-OTH-70854

Brand
Dayton
Item
Manifold Gauge Set: 2 Valves, 3 Hoses, 3 1/8 in Gauge
Category
Analog Manifold Gauge Kits
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4PDG1
Type
3 1/8 in Gauge, For R-22/R-404A/R-407C/R-410A
Hoses
3
Includes
Hanging Hook
Gauge Boots
Yes
Sight Glass
Yes
Product Type
Manifold Gauge Set
For Refrigerant Type
R-22
Hose Connection Type
SAE
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Manifold Gauge Set (MPN 4PDG1) is an analog manifold gauge kit with 2 valves and 3 hoses, featuring 3 1/8 in gauges. It is designed for use with refrigerants R-22, R-404A, R-407C, and R-410A, with SAE hose connections. The set includes a hanging hook, gauge boots, and a sight glass.

Frequently Asked Questions

What is the DAYTON Manifold Gauge Set used for?

The DAYTON Manifold Gauge Set (4PDG1) is used by HVAC technicians to measure pressure and diagnose issues in refrigeration and air conditioning systems. It works with R-22, R-404A, R-407C, and R-410A refrigerants, making it suitable for commercial and residential HVAC maintenance.

What are the specifications of the DAYTON Manifold Gauge Set?

This analog manifold gauge set includes 2 valves, 3 SAE hoses, and 3 1/8 in gauges. It supports R-22, R-404A, R-407C, and R-410A refrigerants. The set comes with a hanging hook, gauge boots, and a sight glass. The manufacturer part number is 4PDG1.

Where to buy the DAYTON Manifold Gauge Set worldwide?

You can source the DAYTON Manifold Gauge Set (4PDG1) through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time.

How to select the right manifold gauge set for R-410A?

For R-410A, ensure the gauge set is rated for its higher pressure range. The DAYTON 4PDG1 is designed for R-410A along with R-22, R-404A, and R-407C. Check that hose connections are SAE type and the set includes a sight glass for monitoring refrigerant flow.
