Dayton High Side Gauge: High Side Gauge, 0 psi to 800 psi, Non-Liquid Filled, 3 1/8 in Dia
The DAYTON High Side Gauge (SKU 4PDK5) is an analog high side pressure gauge designed for use with R-22 refrigerant. It features a 0 psi to 800 psi range, a 3 1/8 inch diameter dial, and a non-liquid filled…
SKU 3G-OTH-71312
Need installation or engineering help?
Ask a question
Product Description
The DAYTON High Side Gauge (SKU 4PDK5) is an analog high side pressure gauge designed for use with R-22 refrigerant. It features a 0 psi to 800 psi range, a 3 1/8 inch diameter dial, and a non-liquid filled construction. The gauge offers an accuracy of ± 2.5% and comes in a red color.
Frequently Asked Questions
What is the DAYTON High Side Gauge used for?
The DAYTON High Side Gauge (4PDK5) is used to measure high-side pressure in HVACR systems, specifically with R-22 refrigerant. It monitors discharge pressure to ensure system efficiency and safety, making it essential for commercial refrigeration and air conditioning maintenance.
What are the specifications of the DAYTON High Side Gauge?
The DAYTON High Side Gauge (4PDK5) has a 0 psi to 800 psi range, a 3 1/8 in diameter dial, and ± 2.5% accuracy. It is non-liquid filled, red in color, and designed for R-22 refrigerant. The manufacturer part number is 4PDK5.
Where to buy the DAYTON High Side Gauge worldwide?
You can source the DAYTON High Side Gauge (4PDK5) through 3G Electric, a global industrial equipment distributor. We handle logistics, customs clearance, and delivery to worldwide locations, ensuring reliable procurement for your HVACR needs.
How to select the right high side gauge for R-22 systems?
To select a high side gauge for R-22, ensure the pressure range covers system operating pressures, like the 0 psi to 800 psi range of the DAYTON 4PDK5. Verify compatibility with R-22 refrigerant and choose a dial size, such as 3 1/8 in, for readability. Accuracy of ± 2.5% is standard for field use.
Used in
Common applications for DaytonDayton Products
3G Electric supplies Dayton analog high side pressure gauges. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
