Dayton Speed Reducer: 20:1, 88 RPM, 3 hp Input Max, 1816 in-lb Output Max, Keyed - Direct-Drive Right-Angle Speed Reducers
DaytonDirect-Drive Right-Angle Speed Reducers

Dayton Speed Reducer: 20:1, 88 RPM, 3 hp Input Max, 1816 in-lb Output Max, Keyed

The DAYTON Speed Reducer (SKU 4Z018) is a direct-drive right-angle speed reducer with a 20:1 ratio, delivering 88 RPM output and a maximum input of 3 hp. It supports a maximum output torque of 1816 in-lb and features…

SKU 3G-OTH-139597

Brand
Dayton
Item
Speed Reducer: 20:1, 88 RPM, 3 hp Input Max, 1816 in-lb Output Max, Keyed
Category
Direct-Drive Right-Angle Speed Reducers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4Z018
Type
88 RPM, 1816 in-lb Output Max, Keyed, 180TC/210C, 4Z018
Input Max
3 hp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Speed Reducer (SKU 4Z018) is a direct-drive right-angle speed reducer with a 20:1 ratio, delivering 88 RPM output and a maximum input of 3 hp. It supports a maximum output torque of 1816 in-lb and features a keyed output shaft. The unit is compatible with 180TC/210C motor frames and can be mounted in any position except with the input motor shaft facing upward.

Frequently Asked Questions

What is the DAYTON Speed Reducer 4Z018 used for?

The DAYTON Speed Reducer 4Z018 is a direct-drive right-angle speed reducer used to reduce motor speed and increase torque in industrial machinery. It is suitable for conveyors, packaging equipment, and material handling systems where a 20:1 ratio and 88 RPM output are required.

What are the specifications of the DAYTON Speed Reducer 4Z018?

The DAYTON Speed Reducer 4Z018 has a 20:1 ratio, 88 RPM output, 3 hp maximum input, and 1816 in-lb maximum output torque. It features a keyed output shaft, fits 180TC/210C motor frames, and can be mounted in any position except with the input motor shaft facing upward.

Where to buy the DAYTON Speed Reducer 4Z018 worldwide?

You can source the DAYTON Speed Reducer 4Z018 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this direct-drive right-angle speed reducer.

How to install the DAYTON Speed Reducer 4Z018?

Mount the DAYTON Speed Reducer 4Z018 in any position except with the input motor shaft facing upward. Ensure the motor frame matches 180TC/210C and the keyed output shaft aligns with the driven load. Use proper alignment and lubrication per generic speed reducer best practices to avoid premature wear.
