Dayton Speed Reducer: 40:1, 44 RPM, 0.5 hp Input Max, 492 in-lb Output Max, Keyed - Direct-Drive Right-Angle Speed Reducers
DaytonDirect-Drive Right-Angle Speed Reducers

Dayton Speed Reducer: 40:1, 44 RPM, 0.5 hp Input Max, 492 in-lb Output Max, Keyed

The DAYTON Speed Reducer (SKU 4Z302) is a direct-drive right-angle speed reducer with a 40:1 ratio, delivering 44 RPM output. It accepts a maximum input of 0.5 hp and provides up to 492 in-lb output torque, featuring…

SKU 3G-OTH-139661

Brand
Dayton
Item
Speed Reducer: 40:1, 44 RPM, 0.5 hp Input Max, 492 in-lb Output Max, Keyed
Category
Direct-Drive Right-Angle Speed Reducers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4Z302
Type
44 RPM, 492 in-lb Output Max, Keyed, 56C, 4Z302
Input Max
0.5 hp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Speed Reducer (SKU 4Z302) is a direct-drive right-angle speed reducer with a 40:1 ratio, delivering 44 RPM output. It accepts a maximum input of 0.5 hp and provides up to 492 in-lb output torque, featuring a keyed shaft and 56C frame. This unit is designed for mounting in any position except with the input motor shaft facing upward.

Frequently Asked Questions

What is the DAYTON Speed Reducer 4Z302 used for?

The DAYTON Speed Reducer 4Z302 is a direct-drive right-angle speed reducer used to reduce motor speed and increase torque in industrial machinery. It is suitable for conveyors, packaging equipment, and material handling systems where a 40:1 ratio and 44 RPM output are required.

What are the specifications of the DAYTON Speed Reducer 4Z302?

The DAYTON Speed Reducer 4Z302 has a 40:1 ratio, 44 RPM output, 0.5 hp maximum input, and 492 in-lb output torque. It features a keyed shaft, 56C frame, and can be mounted in any position except with the input motor shaft facing upward.

Where to buy the DAYTON Speed Reducer 4Z302 worldwide?

You can source the DAYTON Speed Reducer 4Z302 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the speed reducer reaches your facility efficiently.

How to install the DAYTON Speed Reducer 4Z302?

Mount the DAYTON Speed Reducer 4Z302 in any position except with the input motor shaft facing upward. Align the keyed shaft with the driven equipment, secure the 56C frame, and ensure proper lubrication per manufacturer guidelines. Always follow generic best practices for right-angle reducer installation.

Used in

Common applications for Dayton
HVAC ventilation — DAYTON centrifugal upblast roof exhaust fans (SKU 7M7U3) for kitchen exhaust systems
Mechanical power transmission — DAYTON HTD timing pulleys (SKU 404GV0) for conveyor belt drives
Process water handling — DAYTON self-priming centrifugal pumps (SKU 2ZXT4) for dewatering or transfer
Roofing and building services — DAYTON fixed ventilated roof curbs (SKU 4HX59) for filtered supply fan installations
Material handling — DAYTON latch assemblies (SKU 2KEN4) for electric chain hoist hook safety
Industrial air movement — DAYTON downblast roof exhaust fans (SKU 3HFL9) for clean air exhaust in manufacturing plants

Dayton Products

3G Electric supplies Dayton direct-drive right-angle speed reducers. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
