Dayton Hydronic Wall and Ceiling Unit Heater: Steam/Water - Suspended Vertical Hydronic Wall & Ceiling Unit Heaters
DaytonSuspended Vertical Hydronic Wall & Ceiling Unit Heaters

Dayton Hydronic Wall and Ceiling Unit Heater: Steam/Water

The DAYTON Hydronic Wall and Ceiling Unit Heater (SKU 5PV56) is a suspended vertical hydronic unit heater designed for steam or water heating. It delivers 105,200 BtuH output at 200°F water with an air flow of 2,220…

SKU 3G-OTH-67114

Brand
Dayton
Item
Hydronic Wall and Ceiling Unit Heater: Steam/Water
Category
Suspended Vertical Hydronic Wall & Ceiling Unit Heaters
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
5PV56
Type
105,200 BtuH Output @ 200 F Water
Air Flow
2,220 cfm
Fan Guard Type
No Guard
Heating Method
Water
Overall Dimensions - H x W x D
13-5/8 in x 29-1/2 in x 29-1/2 in
Connection Size, Connection Type
2 in, Threaded Male NPT
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Hydronic Wall and Ceiling Unit Heater (SKU 5PV56) is a suspended vertical hydronic unit heater designed for steam or water heating. It delivers 105,200 BtuH output at 200°F water with an air flow of 2,220 cfm, and features a 2-inch threaded male NPT connection. The unit measures 13-5/8 in x 29-1/2 in x 29-1/2 in and comes without a fan guard.

Frequently Asked Questions

What is the DAYTON Hydronic Wall and Ceiling Unit Heater used for?

The DAYTON Hydronic Wall and Ceiling Unit Heater is used for heating commercial or industrial spaces using steam or hot water. It delivers 105,200 BtuH output at 200°F water and 2,220 cfm airflow, making it suitable for warehouses, factories, and large open areas requiring suspended vertical heating.

What are the specifications of the DAYTON 5PV56 unit heater?

The DAYTON 5PV56 is a suspended vertical hydronic unit heater with a heating method of water. It has a 2-inch threaded male NPT connection, air flow of 2,220 cfm, and overall dimensions of 13-5/8 in x 29-1/2 in x 29-1/2 in. It comes without a fan guard and is designed for steam or water heating.

Where to buy the DAYTON 5PV56 unit heater worldwide?

You can source the DAYTON 5PV56 unit heater through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide reliable sourcing for this DAYTON hydronic heater.

How to install a DAYTON hydronic wall and ceiling unit heater?

Install the DAYTON unit heater by suspending it securely from a ceiling or wall using appropriate mounting hardware. Connect the 2-inch threaded male NPT pipes for steam or water supply and return. Ensure proper clearance for airflow and follow local codes. Always consult a qualified HVAC technician for safe installation.
