Dayton Gas Infrared Flat Panel Heater: Natural Gas - Suspended Infrared Flat Panel Gas Ceiling Heaters
DaytonSuspended Infrared Flat Panel Gas Ceiling Heaters

Dayton Gas Infrared Flat Panel Heater: Natural Gas

The DAYTON Gas Infrared Flat Panel Heater (SKU 5VD65) is a suspended infrared flat panel gas ceiling heater for indoor use, fueled by natural gas. It has a 90,000 BtuH heating capacity input and overall dimensions of…

SKU 3G-OTH-66258

Brand
Dayton
Item
Gas Infrared Flat Panel Heater: Natural Gas
Category
Suspended Infrared Flat Panel Gas Ceiling Heaters
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
5VD65
Fuel Type
Natural Gas
For Use Outdoors
Indoor Use Only
Min. Mounting Height
16 to 18 ft
BtuH Heating Capacity Input
90,000
Overall Dimensions - H x W x D
22-1/2 in x 26-5/8 in x 15-1/4 in
Floor Coverage @ Minimum Mounting Height
20 ft x 20 ft
Clearance to Combustibles - Top x Below x Sides
42 in x 98 in x 48 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Gas Infrared Flat Panel Heater (SKU 5VD65) is a suspended infrared flat panel gas ceiling heater for indoor use, fueled by natural gas. It has a 90,000 BtuH heating capacity input and overall dimensions of 22-1/2 in x 26-5/8 in x 15-1/4 in. The unit requires a minimum mounting height of 16 to 18 ft, provides floor coverage of 20 ft x 20 ft, and specifies clearances to combustibles of 42 in (top), 98 in (below), and 48 in (sides).

Frequently Asked Questions

What is the DAYTON Gas Infrared Flat Panel Heater used for?

The DAYTON Gas Infrared Flat Panel Heater (5VD65) is a suspended ceiling heater for indoor industrial spaces. It uses natural gas to provide 90,000 BtuH input, warming floors and objects directly via infrared radiation, ideal for warehouses, workshops, and factories.

What are the specifications of the DAYTON 5VD65 heater?

The DAYTON 5VD65 is a natural gas infrared flat panel heater with 90,000 BtuH input. It measures 22-1/2 in x 26-5/8 in x 15-1/4 in, requires a minimum mounting height of 16 to 18 ft, and provides floor coverage of 20 ft x 20 ft. Clearances to combustibles are 42 in top, 98 in below, and 48 in sides.

Where to buy the DAYTON 5VD65 heater worldwide?

3G Electric supplies the DAYTON 5VD65 gas infrared heater to customers worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this heater to your facility. Contact us for a quote and delivery options.

How to install the DAYTON gas infrared flat panel heater?

Install the DAYTON 5VD65 heater suspended from a ceiling at a minimum height of 16 to 18 ft, ensuring clearances to combustibles of 42 in top, 98 in below, and 48 in sides. Follow local codes and the manufacturer's manual for gas supply and electrical connections. Professional installation is recommended.
