Dayton Supplementary Protector: 6 A Amps, 7.5kA at 480V AC, Screw Clamp, NDB2-63 - D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
DaytonD-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors

Dayton Supplementary Protector: 6 A Amps, 7.5kA at 480V AC, Screw Clamp, NDB2-63

The DAYTON IEC Supplementary Protector (SKU 5ZVF7) is a D-Curve, 3-Pole UL1077 DIN Rail-Mount supplementary protector from the NDB2-63 series, rated at 6 A Amps. It features a Max. AIR Rating of 7.5kA at 480V AC, an…

SKU 3G-OTH-20762

Brand
Dayton
Item
Supplementary Protector: 6 A Amps, 7.5kA at 480V AC, Screw Clamp, NDB2-63
Category
D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
5ZVF7
Series
NDB2-63
Type
7.5kA at 480V AC, Screw Clamp, NDB2-63
AC
480V
Max. AIR Rating
7.5kA at 480V AC
AC Voltage Rating
480V AC
DC Voltage Rating
Not Rated
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON IEC Supplementary Protector (SKU 5ZVF7) is a D-Curve, 3-Pole UL1077 DIN Rail-Mount supplementary protector from the NDB2-63 series, rated at 6 A Amps. It features a Max. AIR Rating of 7.5kA at 480V AC, an AC Voltage Rating of 480V AC, and a Screw Clamp terminal connection; it is Not Rated for DC voltage.

Frequently Asked Questions

What is the DAYTON 5ZVF7 IEC supplementary protector used for?

The DAYTON 5ZVF7 is a D-Curve, 3-Pole UL1077 DIN Rail-Mount supplementary protector rated at 6 A Amps. It protects industrial control circuits and equipment from overloads and short circuits in 480V AC systems, commonly used in panel building and machinery applications.

What are the specifications of the DAYTON 5ZVF7 supplementary protector?

The DAYTON 5ZVF7 is a 6 A Amps, 3-Pole D-Curve supplementary protector from the NDB2-63 series. It has a Max. AIR Rating of 7.5kA at 480V AC, AC Voltage Rating of 480V AC, and Screw Clamp terminals. It is Not Rated for DC voltage and mounts on DIN rail.

Where to buy the DAYTON 5ZVF7 supplementary protector worldwide?

3G Electric supplies the DAYTON 5ZVF7 supplementary protector worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this NDB2-63 series protector.

How to install a DIN rail-mount supplementary protector like the DAYTON 5ZVF7?

To install the DAYTON 5ZVF7, snap it onto a standard 35mm DIN rail. Connect wires using the Screw Clamp terminals, ensuring torque per manufacturer specs. Verify the circuit is de-energized before installation. This D-Curve protector is suitable for motor and transformer branch circuits.
