Dayton Supplementary Protector: 63 A Amps, 7.5kA at 480V AC, Screw Clamp, NDB2-63 - D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
DaytonD-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors

Dayton Supplementary Protector: 63 A Amps, 7.5kA at 480V AC, Screw Clamp, NDB2-63

The DAYTON IEC Supplementary Protector (SKU 5ZVG5) is a D-Curve, 3-Pole UL1077 DIN Rail-Mount supplementary protector rated for 63 A Amps. It features a Max. AIR Rating of 7.5kA at 480V AC, an AC Voltage Rating of…

SKU 3G-OTH-20694

Brand
Dayton
Item
Supplementary Protector: 63 A Amps, 7.5kA at 480V AC, Screw Clamp, NDB2-63
Category
D-Curve, 3-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
5ZVG5
Series
NDB2-63
Type
7.5kA at 480V AC, Screw Clamp, NDB2-63
AC
480V
Max. AIR Rating
7.5kA at 480V AC
AC Voltage Rating
480V AC
DC Voltage Rating
Not Rated
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON IEC Supplementary Protector (SKU 5ZVG5) is a D-Curve, 3-Pole UL1077 DIN Rail-Mount supplementary protector rated for 63 A Amps. It features a Max. AIR Rating of 7.5kA at 480V AC, an AC Voltage Rating of 480V AC, and a Screw Clamp terminal connection. This unit is part of the NDB2-63 series and is not rated for DC voltage.

Frequently Asked Questions

What is the DAYTON IEC Supplementary Protector 5ZVG5 used for?

The DAYTON IEC Supplementary Protector 5ZVG5 is used for overcurrent protection in industrial control panels, HVAC equipment, and machinery. Its D-curve trip characteristic handles high inrush currents from motors and transformers. It is UL1077 listed for branch circuit protection in 480V AC systems.

What are the specifications of the DAYTON 5ZVG5 supplementary protector?

The DAYTON 5ZVG5 is a 3-pole, D-curve supplementary protector rated 63 A at 480V AC with a maximum interrupting rating of 7.5kA at 480V AC. It uses screw clamp terminals, is part of the NDB2-63 series, and is not rated for DC voltage. It mounts on a DIN rail.

Where to buy the DAYTON 5ZVG5 supplementary protector worldwide?

You can source the DAYTON 5ZVG5 supplementary protector through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this NDB2-63 series unit.

How to install the DAYTON 5ZVG5 supplementary protector?

Install the DAYTON 5ZVG5 by snapping it onto a 35mm DIN rail. Connect line and load wires using the screw clamp terminals, torquing to manufacturer specifications. Ensure the protector is used within its 480V AC rating and 63 A ampacity. Follow NEC and local codes for supplementary protection.
