Dayton Exhaust Fan with Drive Package: Belt Drive, 30 in Blade, 1 1/2 hp, 13,639 cfm - Belt-Drive Panel Exhaust Fans with Drive Package
DaytonBelt-Drive Panel Exhaust Fans with Drive Package

Dayton Exhaust Fan with Drive Package: Belt Drive, 30 in Blade, 1 1/2 hp, 13,639 cfm

The DAYTON 7M894 is an unassembled belt-drive panel exhaust fan with drive package, featuring a 30-inch blade, 1 1/2 hp motor, and 13,639 cfm airflow. It operates on 115/208-230V AC, single-phase power, with an open…

SKU 3G-OTH-81173

Brand
Dayton
Item
Exhaust Fan with Drive Package: Belt Drive, 30 in Blade, 1 1/2 hp, 13,639 cfm
Category
Belt-Drive Panel Exhaust Fans with Drive Package
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
7M894
Type
1 1/2 hp, 13,639 cfm, 1 ph
AC
115/208-230V
Blade
30 in
Assembled
Unassembled
Guard Type
None
Frame Finish
Zinc Plated
Frame Material
Steel
Motor Enclosure
Open Dripproof
Enclosure Design
Open Dripproof Motor
Motor Insulation
Class B
Number of Speeds
1
Nameplate Voltage
115/208-230V AC
Guard Type Subheads
Without Intake Guards
Method of Construction
Cast
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON 7M894 is an unassembled belt-drive panel exhaust fan with drive package, featuring a 30-inch blade, 1 1/2 hp motor, and 13,639 cfm airflow. It operates on 115/208-230V AC, single-phase power, with an open dripproof motor enclosure and Class B insulation. The fan has a zinc-plated steel frame, cast construction, and no intake guards.

Frequently Asked Questions

What is the DAYTON 7M894 exhaust fan used for?

The DAYTON 7M894 belt-drive panel exhaust fan is used for high-volume air movement in industrial and commercial facilities, such as warehouses, factories, and workshops. It delivers 13,639 cfm to remove heat, fumes, or stale air, and is designed for wall or panel mounting.

What are the specifications of the DAYTON 7M894 exhaust fan?

The DAYTON 7M894 has a 30-inch blade, 1 1/2 hp motor, 13,639 cfm airflow, and operates on 115/208-230V AC single-phase power. It features an open dripproof motor with Class B insulation, a zinc-plated steel frame, cast construction, and no intake guards. It is supplied unassembled.

Where to buy the DAYTON 7M894 exhaust fan worldwide?

You can source the DAYTON 7M894 exhaust fan through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the DAYTON 7M894 belt-drive exhaust fan?

Install the DAYTON 7M894 by mounting the unassembled fan panel securely to a wall or structural frame. Assemble the belt-drive package per the manual, ensuring proper belt tension and alignment. Connect the motor to a 115/208-230V AC single-phase supply. Always follow local electrical codes and use a licensed electrician.
