EATON Pilot Light: 30 mm Panel Mounting Size, Yellow, LED - LED Pilot-Lights
EATONLED Pilot-Lights

EATON Pilot Light: 30 mm Panel Mounting Size, Yellow, LED

The EATON HT8GTYF7 is a 30 mm panel-mounting-size LED pilot light from the HT800 series, featuring a yellow LED with a maximum supply voltage rating of 120 V AC/DC. This pilot light includes a push-to-test function…

SKU 3G-OTH-35401

Brand
EATON
Item
Pilot Light: 30 mm Panel Mounting Size, Yellow, LED
Category
LED Pilot-Lights
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
HT8GTYF7
Series
HT800
Type
Yellow, LED
Includes Push-To-Test
Push-To-Test Included
AC/DC Max Volt Rating (Supply)
120 V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON HT8GTYF7 is a 30 mm panel-mounting-size LED pilot light from the HT800 series, featuring a yellow LED with a maximum supply voltage rating of 120 V AC/DC. This pilot light includes a push-to-test function for verifying operation.

Frequently Asked Questions

What is the EATON HT8GTYF7 pilot light used for?

The EATON HT8GTYF7 is a 30 mm panel-mounting-size LED pilot light used as a visual status indicator on industrial control panels, machinery, and automation equipment. Its yellow LED signals operational states or warnings, and the push-to-test function allows operators to verify the light is working without removing it from the panel.

What are the specifications of the EATON HT8GTYF7 pilot light?

The EATON HT8GTYF7 is a yellow LED pilot light from the HT800 series with a 30 mm panel mounting size. It has a maximum supply voltage rating of 120 V AC/DC and includes a push-to-test feature for verifying operation. The manufacturer part number is HT8GTYF7.

Where to buy the EATON HT8GTYF7 pilot light worldwide?

You can source the EATON HT8GTYF7 pilot light worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we supply genuine EATON components to industrial buyers internationally.

How to install the EATON HT8GTYF7 pilot light?

To install the EATON HT8GTYF7, mount it in a 30 mm panel cutout and secure it with the provided locking ring. Connect the supply voltage (up to 120 V AC/DC) per the wiring diagram. After installation, use the push-to-test button to confirm the LED illuminates. Follow standard industrial electrical safety practices.
