EATON Supplementary Protector: 4 A Amps, 48V DC, 15kA at 277V AC, Lug, FAZ, 277/480V AC - C-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATONC-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 4 A Amps, 48V DC, 15kA at 277V AC, Lug, FAZ, 277/480V AC

The EATON FAZ-C4/1-SP is a C-curve, 1-pole UL1077 DIN rail-mount supplementary protector rated at 4 A. It carries a maximum AIR rating of 15 kA at 277 V AC and is rated for 277/480 V AC and 48 V DC. This unit…

SKU 3G-OTH-19652

Brand
EATON
Item
Supplementary Protector: 4 A Amps, 48V DC, 15kA at 277V AC, Lug, FAZ, 277/480V AC
Category
C-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-C4/1-SP
Series
FAZ
Type
15kA at 277V AC, Lug, FAZ, C
AC
277/480V
DC
48V
Curve Type
C
Max. AIR Rating
15kA at 277V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
48V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-C4/1-SP is a C-curve, 1-pole UL1077 DIN rail-mount supplementary protector rated at 4 A. It carries a maximum AIR rating of 15 kA at 277 V AC and is rated for 277/480 V AC and 48 V DC. This unit features lug terminal connections and is part of the FAZ series.

Frequently Asked Questions

What is the EATON FAZ-C4/1-SP supplementary protector used for?

The EATON FAZ-C4/1-SP is a C-curve, 1-pole UL1077 DIN rail-mount supplementary protector rated at 4 A. It protects industrial control circuits, HVAC equipment, and panelboards from overcurrent and short circuits in 277/480 V AC or 48 V DC systems.

What are the specifications of the EATON FAZ-C4/1-SP?

The EATON FAZ-C4/1-SP is rated 4 A with a C-curve trip characteristic. It has an AC voltage rating of 277/480 V AC, a DC voltage rating of 48 V DC, and a maximum AIR rating of 15 kA at 277 V AC. Terminal connection is lug type, and it is part of the FAZ series.

Where to buy the EATON FAZ-C4/1-SP worldwide?

3G Electric supplies the EATON FAZ-C4/1-SP worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this supplementary protector to any country.

How to install the EATON FAZ-C4/1-SP on a DIN rail?

To install the EATON FAZ-C4/1-SP, snap it onto a standard 35 mm DIN rail until it locks. Connect line and load wires to the lug terminals using the appropriate torque per the manufacturer's instructions. Ensure the circuit is de-energized before installation and follow local electrical codes.
