EATON Supplementary Protector: 40 A Amps, 48V DC, 15kA at 277V AC, Lug, FAZ, 277/480V AC - C-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATONC-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 40 A Amps, 48V DC, 15kA at 277V AC, Lug, FAZ, 277/480V AC

The EATON FAZ-C40/1-SP is a 40 A C-curve, 1-pole UL1077 DIN rail-mount supplementary protector from the FAZ series. It features a lug terminal connection and is rated for 277/480V AC with a maximum AIR rating of 15kA…

SKU 3G-OTH-20048

Brand
EATON
Item
Supplementary Protector: 40 A Amps, 48V DC, 15kA at 277V AC, Lug, FAZ, 277/480V AC
Category
C-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-C40/1-SP
Series
FAZ
Type
15kA at 277V AC, Lug, FAZ, C
AC
277/480V
DC
48V
Curve Type
C
Max. AIR Rating
15kA at 277V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
48V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-C40/1-SP is a 40 A C-curve, 1-pole UL1077 DIN rail-mount supplementary protector from the FAZ series. It features a lug terminal connection and is rated for 277/480V AC with a maximum AIR rating of 15kA at 277V AC, as well as 48V DC.
