EATON Supplementary Protector: 6 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ - C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATONC-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 6 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ

The EATON FAZ-C6/2 is a C-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated at 6 A. It carries a maximum AIR rating of 15 kA at 277/480 V AC and a DC voltage rating of 96 V DC, with lug-type terminal…

SKU 3G-OTH-21288

Brand
EATON
Item
Supplementary Protector: 6 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ
Category
C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-C6/2
Series
FAZ
Type
15kA at 277/480V AC, Lug, FAZ, C
AC
277/480V
DC
96V
Curve Type
C
Max. AIR Rating
15kA at 277/480V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
96V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-C6/2 is a C-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated at 6 A. It carries a maximum AIR rating of 15 kA at 277/480 V AC and a DC voltage rating of 96 V DC, with lug-type terminal connections.

Frequently Asked Questions

What is the EATON FAZ-C6/2 supplementary protector used for?

The EATON FAZ-C6/2 is a C-curve, 2-pole UL1077 supplementary protector rated at 6 A. It protects branch circuits and equipment against overloads and short circuits in industrial control panels, HVAC systems, and lighting applications where overcurrent protection is needed.

What are the specifications of the EATON FAZ-C6/2?

The EATON FAZ-C6/2 is rated 6 A with an AC voltage rating of 277/480 V AC and a DC voltage rating of 96 V DC. It has a maximum AIR rating of 15 kA at 277/480 V AC, a C-curve trip characteristic, and lug-type terminal connections. It is part of the FAZ series.

Where to buy the EATON FAZ-C6/2 worldwide?

You can source the EATON FAZ-C6/2 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this supplementary protector.

How to install the EATON FAZ-C6/2 supplementary protector?

Install the EATON FAZ-C6/2 on a standard DIN rail. Ensure the circuit is de-energized before mounting. Connect line and load wires to the lug terminals, torqueing to manufacturer specifications. Verify the C-curve matches your application's inrush characteristics. Always follow local electrical codes.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas

EATON Products

3G Electric supplies EATON c-curve, 2-pole ul1077 din rail-mount supplementary protectors. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
