EATON Supplementary Protector: 32 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ - C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATONC-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 32 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ

The EATON FAZ-C32/2 is a C-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated for 32 A. It supports AC voltages up to 277/480V AC and DC voltages up to 96V DC, with a maximum interrupting rating of…

SKU 3G-OTH-21269

Brand
EATON
Item
Supplementary Protector: 32 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ
Category
C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-C32/2
Series
FAZ
Type
15kA at 277/480V AC, Lug, FAZ, C
AC
277/480V
DC
96V
Curve Type
C
Max. AIR Rating
15kA at 277/480V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
96V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-C32/2 is a C-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated for 32 A. It supports AC voltages up to 277/480V AC and DC voltages up to 96V DC, with a maximum interrupting rating of 15kA at 277/480V AC. The unit features lug terminal connections and is part of EATON's FAZ series.
