EATON Supplementary Protector: 25 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ - C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATONC-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 25 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ

The EATON FAZ-C25/2 is a 25 A, C-Curve, 2-pole UL1077 DIN rail-mount supplementary protector from the FAZ series. It is rated for 277/480V AC with a maximum interrupting rating of 15kA at that voltage, and also…

SKU 3G-OTH-21264

Brand
EATON
Item
Supplementary Protector: 25 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ
Category
C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-C25/2
Series
FAZ
Type
15kA at 277/480V AC, Lug, FAZ, C
AC
277/480V
DC
96V
Curve Type
C
Max. AIR Rating
15kA at 277/480V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
96V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-C25/2 is a 25 A, C-Curve, 2-pole UL1077 DIN rail-mount supplementary protector from the FAZ series. It is rated for 277/480V AC with a maximum interrupting rating of 15kA at that voltage, and also carries a 96V DC rating. The unit features lug-type terminal connections.
