EATON Supplementary Protector: 5 A Amps, 96V DC, 15kA at 415V AC, Lug, FAZ, 277/480V AC - B-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATONB-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 5 A Amps, 96V DC, 15kA at 415V AC, Lug, FAZ, 277/480V AC

The EATON FAZ-B5/2 is a B-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated at 5 A. It features a maximum AIR rating of 15 kA at 415 V AC, AC voltage rating of 277/480 V AC, and DC voltage rating of…

SKU 3G-OTH-21648

Brand
EATON
Item
Supplementary Protector: 5 A Amps, 96V DC, 15kA at 415V AC, Lug, FAZ, 277/480V AC
Category
B-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-B5/2
Series
FAZ
Type
15kA at 415V AC, Lug, FAZ, B
AC
277/480V
DC
96V
Curve Type
B
Max. AIR Rating
15kA at 415V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
96V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-B5/2 is a B-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated at 5 A. It features a maximum AIR rating of 15 kA at 415 V AC, AC voltage rating of 277/480 V AC, and DC voltage rating of 96 V DC, with lug terminal connections.

Frequently Asked Questions

What is the EATON FAZ-B5/2 supplementary protector used for?

The EATON FAZ-B5/2 is a B-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated at 5 A. It protects branch circuits and equipment from overcurrent and short circuits in industrial control panels, HVAC systems, and machinery across 14 industrial departments.

What are the specifications of the EATON FAZ-B5/2?

The EATON FAZ-B5/2 has a 5 A rating, AC voltage rating of 277/480 V AC, DC voltage rating of 96 V DC, and a maximum AIR rating of 15 kA at 415 V AC. It features a B curve, lug terminal connections, and is part of the FAZ series.

Where to buy the EATON FAZ-B5/2 worldwide?

3G Electric supplies the EATON FAZ-B5/2 worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this supplementary protector.
