EATON Supplementary Protector: 15 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ - B-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATONB-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 15 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ

The EATON FAZ-B15/2 is a B-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated for 15 A. It supports AC voltages up to 277/480V AC and DC voltages up to 96V DC, with a maximum AIR rating of 15kA at…

SKU 3G-OTH-21724

Brand
EATON
Item
Supplementary Protector: 15 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ
Category
B-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-B15/2
Series
FAZ
Type
15kA at 277/480V AC, Lug, FAZ, B
AC
277/480V
DC
96V
Curve Type
B
Max. AIR Rating
15kA at 277/480V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
96V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-B15/2 is a B-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated for 15 A. It supports AC voltages up to 277/480V AC and DC voltages up to 96V DC, with a maximum AIR rating of 15kA at 277/480V AC. This unit features lug terminal connections and is part of the FAZ series from EATON.

Frequently Asked Questions

What is the EATON FAZ-B15/2 supplementary protector used for?

The EATON FAZ-B15/2 is a B-curve, 2-pole UL1077 supplementary protector rated for 15 A. It protects branch circuits and equipment from overcurrent and short circuits in industrial control panels, HVAC systems, and machinery, supporting AC up to 277/480V and DC up to 96V.

What are the specifications of the EATON FAZ-B15/2?

The EATON FAZ-B15/2 is rated 15 A with a B-curve trip characteristic. It handles AC voltages up to 277/480V AC and DC voltages up to 96V DC, with a maximum AIR rating of 15kA at 277/480V AC. Terminal connection is lug type, and it mounts on a DIN rail as part of the FAZ series.

Where to buy the EATON FAZ-B15/2 worldwide?

3G Electric supplies the EATON FAZ-B15/2 supplementary protector to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this UL1077 DIN rail-mount device.

How to install the EATON FAZ-B15/2 on a DIN rail?

To install the EATON FAZ-B15/2, snap it onto a standard 35 mm DIN rail. Ensure the rail is clean and the device clips engage firmly. Connect line and load wires to the lug terminals using the appropriate torque per the manufacturer's instructions. Always de-energize the circuit before installation.
