EATON Lighted Rocker Switch: 2 Positions, SPST, Off/Momentary On - General Purpose Rocker Switches
EATONGeneral Purpose Rocker Switches

EATON Lighted Rocker Switch: 2 Positions, SPST, Off/Momentary On

The EATON Lighted Rocker Switch is a general-purpose rocker switch from the Series 8005, featuring a 2-position, SPST, Off/Momentary On configuration with green illumination. It is rated for AC contact at 10 A @ 250…

SKU 3G-OTH-34762

Brand
EATON
Item
Lighted Rocker Switch: 2 Positions, SPST, Off/Momentary On
Category
General Purpose Rocker Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
8005K35N113V32
Series
8005
Horsepower
3/4 hp @ 250 V
Switch Color
Black
Includes Lens
Lens Included
Displayed Brand
EATON
AC Contact Rating
10 A @ 250 V
DC Contact Rating
15 A @ 28 V
Includes Lamp Module
Lamp Module Included
Operator Illumination
Illuminated
Terminal Connection Type
1/4 in Spade
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Lighted Rocker Switch is a general-purpose rocker switch from the Series 8005, featuring a 2-position, SPST, Off/Momentary On configuration with green illumination. It is rated for AC contact at 10 A @ 250 V and DC contact at 15 A @ 28 V, with a horsepower rating of 3/4 hp @ 250 V. The switch includes a lamp module and lens, has a black color, and uses 1/4 in spade terminal connections.

Frequently Asked Questions

What is the EATON Lighted Rocker Switch used for?

The EATON Lighted Rocker Switch is a general-purpose switch for industrial control panels, machinery, and equipment requiring momentary on/off control. Its green illumination indicates active status, and it handles AC loads up to 10 A @ 250 V or DC loads up to 15 A @ 28 V, plus 3/4 hp motor loads.

What are the specifications of the EATON Lighted Rocker Switch 8005K35N113V32?

This SPST switch has 2 positions (Off/Momentary On), AC contact rating 10 A @ 250 V, DC contact rating 15 A @ 28 V, and horsepower rating 3/4 hp @ 250 V. It includes a lamp module and lens, black color, and 1/4 in spade terminals. The EATON Series 8005 design ensures reliable performance.

Where to buy the EATON Lighted Rocker Switch worldwide?

3G Electric supplies the EATON Lighted Rocker Switch (MPN 8005K35N113V32) to customers worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this general-purpose rocker switch.

How to install the EATON Lighted Rocker Switch?

Install the EATON Lighted Rocker Switch by connecting 1/4 in spade terminals to your circuit, ensuring power is off. Mount it in a standard panel cutout, then test the Off/Momentary On function. The included lamp module and lens are pre-installed. Follow local electrical codes and use appropriate wire gauge for 10 A @ 250 V.
