EATON Illuminated Push Button: 30 mm, Metallic, Extended Profile
The EATON Illuminated Push Button (SKU 31HL06) is a 30 mm metallic, extended-profile push button operator from the 10250T series. It features momentary action with 1NO/1NC contacts, rated at 10 A @ 600 V AC and 2.5 A…
SKU 3G-OTH-32592
Need installation or engineering help?
Ask a question
Product Description
The EATON Illuminated Push Button (SKU 31HL06) is a 30 mm metallic, extended-profile push button operator from the 10250T series. It features momentary action with 1NO/1NC contacts, rated at 10 A @ 600 V AC and 2.5 A @ 250 V DC. The illuminated operator is constructed from metal, providing a durable interface for industrial control applications.
Frequently Asked Questions
What is the EATON illuminated push button used for?
The EATON illuminated push button is used as a momentary operator in industrial control panels, machinery, and process automation. Its 30 mm metallic extended profile provides a durable interface for start/stop or pilot-duty switching in harsh environments, with visual indication via built-in illumination.
What are the specifications of the EATON 10250T828AD24 push button?
The EATON 10250T828AD24 is a 30 mm metallic illuminated push button from the 10250T series. It features momentary action with 1NO/1NC contacts, rated at 10 A @ 600 V AC and 2.5 A @ 250 V DC. The operator is illuminated and made of metal for durability.
Where to buy the EATON 10250T828AD24 push button worldwide?
You can source the EATON 10250T828AD24 illuminated push button through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this EATON 10250T series component.
How to install the EATON 30 mm illuminated push button?
Install the EATON 30 mm illuminated push button by mounting it through a standard 30 mm panel cutout and securing with the provided locknut. Wire the 1NO/1NC contacts per your control schematic, ensuring the supply voltage matches the illumination rating. Follow standard industrial wiring practices for safety.
