EATON Illuminated Push Button: 30 mm, Metallic, Extended Profile
The EATON Illuminated Push Button (SKU 31HL12, MPN E34EX828AD24) is a 30 mm metallic, extended-profile push button operator from the E34 series. This momentary-action device features a 1NO/1NC contact configuration…
SKU 3G-OTH-32449
Need installation or engineering help?
Ask a question
Product Description
The EATON Illuminated Push Button (SKU 31HL12, MPN E34EX828AD24) is a 30 mm metallic, extended-profile push button operator from the E34 series. This momentary-action device features a 1NO/1NC contact configuration and is illuminated. It is rated for AC contacts at 10 A @ 600 V and DC contacts at 2.5 A @ 250 V.
Frequently Asked Questions
What is the EATON illuminated push button used for?
The EATON illuminated push button is used for momentary control in industrial machinery, panel building, and process automation. Its 30 mm metallic extended profile and 1NO/1NC contacts suit heavy-duty start/stop and signaling applications where visual operator feedback is required.
What are the specifications of the EATON E34EX828AD24?
The EATON E34EX828AD24 is a 30 mm metallic, extended-profile illuminated push button from the E34 series. It has momentary action, 1NO/1NC contacts, AC contact rating of 10 A @ 600 V, and DC contact rating of 2.5 A @ 250 V.
Where to buy the EATON E34EX828AD24 worldwide?
You can source the EATON E34EX828AD24 illuminated push button through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring compliance and timely arrival for your project.
How to install the EATON illuminated push button?
Install the EATON illuminated push button into a 30 mm panel cutout, secure with the provided locknut, and wire the 1NO/1NC contacts per your control schematic. Ensure the supply voltage matches the illumination rating. Follow standard industrial wiring practices and verify isolation before energizing.
