EATON Illuminated Push Button: 30 mm, Metallic, Extended Profile
The EATON Illuminated Push Button is a 30 mm metallic extended-profile push button operator from the E34 series, featuring a momentary action and 1NO/1NC contact configuration. It is rated for 10 A @ 600 V AC and 2.5…
SKU 3G-OTH-32582
Need installation or engineering help?
Ask a question
Product Description
The EATON Illuminated Push Button is a 30 mm metallic extended-profile push button operator from the E34 series, featuring a momentary action and 1NO/1NC contact configuration. It is rated for 10 A @ 600 V AC and 2.5 A @ 250 V DC, with illuminated operator illumination.
Frequently Asked Questions
What is the EATON E34EX828AD2A illuminated push button used for?
The EATON E34EX828AD2A is a 30 mm metallic illuminated push button used for momentary control in industrial machinery, panel building, and process automation. Its 1NO/1NC contact configuration and 10 A @ 600 V AC rating make it suitable for motor start/stop and signaling applications in harsh environments.
What are the specifications of the EATON E34EX828AD2A push button?
The EATON E34EX828AD2A is a momentary-action, illuminated push button from the E34 series. It has a metallic extended profile, 1NO/1NC contacts, AC contact rating of 10 A @ 600 V, and DC contact rating of 2.5 A @ 250 V. The operator illumination is built-in, and the push button material is metallic.
Where to buy the EATON E34EX828AD2A push button worldwide?
You can source the EATON E34EX828AD2A illuminated push button through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine EATON components for industrial applications.
How to install the EATON E34EX828AD2A illuminated push button?
Install the EATON E34EX828AD2A by mounting it in a 30 mm panel cutout, securing with the provided locknut. Wire the 1NO/1NC contacts according to your control circuit, ensuring the supply voltage matches the illumination rating. Use proper torque on terminals and test momentary action before energizing the system.
Used in
Common applications for EATONEATON Products
3G Electric supplies EATON illuminated extended-length push buttons. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
