EATON Selector Switch: 30 mm Panel Mounting Size, 3 Positions, Extended Lever

The EATON 10250ED1117-3LR is a 30 mm illuminated selector switch used for industrial panel control, enabling three-position maintained switching with a long-handled knob. It suits applications requiring reliable On/On/On action, such as motor control or process sequencing, across 14 industrial departments.

This EATON 10250T Series switch has a 30 mm panel mounting size, 3 positions with maintained action, AC contact rating 10 A @ 660 V, DC contact rating 5 A @ 250 V, polymer operator head, metallic bezel, and cam 3. It is illuminated with a long-handled knob and not rated for hazardous locations.

3G Electric supplies the EATON 10250ED1117-3LR selector switch worldwide, handling full logistics and customs clearance. As a global industrial solutions provider, we source and deliver this 30 mm illuminated switch to any location, ensuring compliance with your procurement requirements.

Install the EATON 10250ED1117-3LR by mounting it in a 30 mm panel cutout, securing the metallic bezel, and wiring the 1NO contact per the maintained action diagram. Ensure power is off, use proper torque on terminals, and verify the long-handled knob rotates freely across all three On positions.
