EATON Molded Case Circuit Breaker: 15 A Amps, 65kA at 480V AC, Instantaneous - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Molded Case Circuit Breaker: 15 A Amps, 65kA at 480V AC, Instantaneous

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PN6, MPN PDG23M0015MRAJ) is a 15 A rated device from the PD Series with a Frame Size of 2. It features a maximum AIR rating of 65kA at 480V AC, an…

SKU 3G-OTH-24463

Brand
EATON
Item
Molded Case Circuit Breaker: 15 A Amps, 65kA at 480V AC, Instantaneous
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG23M0015MRAJ
Series
PD Series
Type
65kA at 480V AC, Instantaneous, ABC, Load Side Lug
Frame Size
2
Max. AIR Rating
65kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Instantaneous
Terminal Connection
Load Side Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 408PN6, MPN PDG23M0015MRAJ) is a 15 A rated device from the PD Series with a Frame Size of 2. It features a maximum AIR rating of 65kA at 480V AC, an instantaneous trip function, ABC phase connection, and load side lug terminals.

Frequently Asked Questions

What is the EATON Power Defense Molded Case Circuit Breaker used for?

The EATON Power Defense Molded Case Circuit Breaker is used for overcurrent protection in industrial and commercial electrical distribution systems. It safeguards circuits and equipment from damage due to short circuits or overloads, with a 15 A rating and 65kA interrupting capacity at 480V AC.

What are the specifications of the EATON PDG23M0015MRAJ circuit breaker?

The EATON PDG23M0015MRAJ is a 15 A molded case circuit breaker from the PD Series, Frame Size 2. It has a maximum AIR rating of 65kA at 480V AC, instantaneous trip, ABC phase connection, and load side lug terminals. It is part of the Power Defense line.

Where to buy the EATON PDG23M0015MRAJ circuit breaker worldwide?

You can source the EATON PDG23M0015MRAJ circuit breaker worldwide through 3G Electric. As a global industrial equipment distributor since 1990, 3G Electric handles full logistics, customs clearance, and delivery to your location. Contact them for availability and lead time.

How to select the correct EATON Power Defense circuit breaker for your application?

To select the correct EATON Power Defense circuit breaker, verify your system voltage (480V AC), required amp rating (15 A), and interrupting capacity (65kA). Ensure the trip type (instantaneous), phase connection (ABC), and terminal type (load side lug) match your panel. Consult a licensed electrician for code compliance.
