EATON Circuit Breaker: 125 A Amps, 65 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Circuit Breaker: 125 A Amps, 65 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT66, MPN PDG13M0125TFFJ) is a 125 A, Frame 1 device with a maximum AIR rating of 65 kA at 480V AC. It features a fixed instantaneous trip, ABC phase…

SKU 3G-OTH-24630

Brand
EATON
Item
Circuit Breaker: 125 A Amps, 65 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG13M0125TFFJ
Type
65 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs, Std
Frame Size
125A/Frame 1
Max. AIR Rating
65 kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Standard Line and Load Lugs
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT66, MPN PDG13M0125TFFJ) is a 125 A, Frame 1 device with a maximum AIR rating of 65 kA at 480V AC. It features a fixed instantaneous trip, ABC phase connection, and standard line and load lugs for terminal connection.

Frequently Asked Questions

What is the EATON Power Defense molded case circuit breaker used for?

The EATON Power Defense molded case circuit breaker (MPN PDG13M0125TFFJ) protects electrical circuits from overloads and short circuits in industrial and commercial power distribution systems. It is rated 125 A with a 65 kA interrupting capacity at 480V AC, suitable for high-fault applications.

What are the specifications of the EATON PDG13M0125TFFJ circuit breaker?

This EATON circuit breaker has a 125 A frame size (Frame 1), a maximum AIR rating of 65 kA at 480V AC, fixed instantaneous trip, ABC phase connection, and standard line and load lugs. It is a Power Defense molded case breaker, part number PDG13M0125TFFJ.

Where to buy the EATON PDG13M0125TFFJ circuit breaker worldwide?

3G Electric supplies the EATON Power Defense circuit breaker (PDG13M0125TFFJ) to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this 125 A, 65 kA at 480V AC breaker.

How to select the right EATON molded case circuit breaker for your application?

Select an EATON molded case circuit breaker by matching the continuous current rating (e.g., 125 A), interrupting capacity (e.g., 65 kA at 480V AC), and trip characteristics (fixed instantaneous) to your system's fault current and load requirements. Verify phase connection (ABC) and terminal type (line/load lugs) for proper installation.
