EATON Safety Interlock Switch: LS-Titan Series - Key-Actuated Safety-Interlock Switches
EATONKey-Actuated Safety-Interlock Switches

EATON Safety Interlock Switch: LS-Titan Series

The EATON LS-Titan Series Safety Interlock Switch (MPN LS-S11-120AFT-ZBZ-X) is a key-actuated safety-interlock switch with a 1NO/1NC contact configuration. It features a front key hole location and an elbowed…

SKU 3G-OTH-30648

Brand
EATON
Item
Safety Interlock Switch: LS-Titan Series
Category
Key-Actuated Safety-Interlock Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
LS-S11-120AFT-ZBZ-X
Series
LS-Titan
Key Hole Location
Front
Actuating Key Type
Elbowed
Terminal Connection Type
Screw Terminals
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON LS-Titan Series Safety Interlock Switch (MPN LS-S11-120AFT-ZBZ-X) is a key-actuated safety-interlock switch with a 1NO/1NC contact configuration. It features a front key hole location and an elbowed actuating key type, with screw terminals for connection.

Frequently Asked Questions

What is the EATON LS-Titan safety interlock switch used for?

The EATON LS-Titan safety interlock switch is used to guard hazardous machinery by interrupting power when the guard is opened. It is common in industrial automation, packaging, and material handling applications where operator safety is critical.

What are the specifications of the EATON LS-S11-120AFT-ZBZ-X?

The EATON LS-S11-120AFT-ZBZ-X is a key-actuated safety-interlock switch from the LS-Titan series. It has a 1NO/1NC contact configuration, an elbowed actuating key, front key hole location, and screw terminals for connection.

Where to buy the EATON LS-S11-120AFT-ZBZ-X worldwide?

You can source the EATON LS-S11-120AFT-ZBZ-X through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring compliance with local regulations.

How to install the EATON LS-Titan safety interlock switch?

Mount the switch on the machine guard frame and align the elbowed key with the front key hole. Connect the 1NO/1NC contacts via screw terminals per the wiring diagram. Ensure the key actuates the switch fully before securing the guard.
