EATON Safety Interlock Switch: LS-Titan Series - Key-Actuated Safety-Interlock Switches
EATONKey-Actuated Safety-Interlock Switches

EATON Safety Interlock Switch: LS-Titan Series

The EATON LS-Titan Series Safety Interlock Switch (MPN LS-S11-120AMT-ZBZ-X) is a key-actuated safety-interlock switch with 1NO/1NC contacts. It features an elbowed actuating key, left key hole location, and screw…

SKU 3G-OTH-30304

Brand
EATON
Item
Safety Interlock Switch: LS-Titan Series
Category
Key-Actuated Safety-Interlock Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
LS-S11-120AMT-ZBZ-X
Series
LS-Titan
Key Hole Location
Left
Actuating Key Type
Elbowed
Terminal Connection Type
Screw Terminals
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON LS-Titan Series Safety Interlock Switch (MPN LS-S11-120AMT-ZBZ-X) is a key-actuated safety-interlock switch with 1NO/1NC contacts. It features an elbowed actuating key, left key hole location, and screw terminal connections.

Frequently Asked Questions

What is the EATON LS-Titan safety interlock switch used for?

The EATON LS-Titan safety interlock switch (LS-S11-120AMT-ZBZ-X) is used to guard access to hazardous machinery by interrupting power when the guard is opened. It is common in industrial automation, packaging, and material handling applications where operator safety is critical.

What are the specifications of the EATON LS-S11-120AMT-ZBZ-X?

This EATON LS-Titan safety interlock switch features 1NO/1NC contacts, an elbowed actuating key, left key hole location, and screw terminal connections. It is designed for key-actuated interlocking in industrial safety circuits.

Where to buy the EATON LS-S11-120AMT-ZBZ-X worldwide?

3G Electric supplies the EATON LS-Titan safety interlock switch (LS-S11-120AMT-ZBZ-X) worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this EATON safety component.

How to install an EATON LS-Titan safety interlock switch?

Mount the EATON LS-Titan switch securely to the machine guard frame. Connect the 1NO/1NC contacts via the screw terminals to your safety relay or PLC input. Ensure the elbowed actuating key aligns with the key hole when the guard is closed. Follow EATON's wiring diagram for proper safety circuit integration.
