EATON Miniature Circuit Breaker: 40 A, 277/480V AC, Three Phase, 14kA at 277/480V AC - GHB Series, Bolt-On Eaton Cutler-Hammer Miniature Circuit Breakers
EATONGHB Series, Bolt-On Eaton Cutler-Hammer Miniature Circuit Breakers

EATON Miniature Circuit Breaker: 40 A, 277/480V AC, Three Phase, 14kA at 277/480V AC

The EATON GHB3040 is a three-pole, bolt-on miniature circuit breaker from the GHB Series, rated at 40 A and 277/480V AC with a 14kA interrupting capacity at 277/480V AC. It is designed for use in Eaton Powerline…

SKU 3G-OTH-127730

Brand
EATON
Item
Miniature Circuit Breaker: 40 A, 277/480V AC, Three Phase, 14kA at 277/480V AC
Category
GHB Series, Bolt-On Eaton Cutler-Hammer Miniature Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
GHB3040
Type
Three Phase, 14kA at 277/480V AC, Std
AC
277/480V
Poles
3
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON GHB3040 is a three-pole, bolt-on miniature circuit breaker from the GHB Series, rated at 40 A and 277/480V AC with a 14kA interrupting capacity at 277/480V AC. It is designed for use in Eaton Powerline Panelboards and features a standard trip characteristic.

Frequently Asked Questions

What is the EATON GHB3040 miniature circuit breaker used for?

The EATON GHB3040 is a three-pole, bolt-on miniature circuit breaker rated at 40 A and 277/480V AC. It is designed for branch-circuit protection in Eaton Powerline Panelboards, providing overcurrent protection in commercial and industrial electrical distribution systems.

What are the specifications of the EATON GHB3040?

The EATON GHB3040 is a three-pole miniature circuit breaker with a 40 A rating, 277/480V AC voltage, and a 14kA interrupting capacity at 277/480V AC. It features a standard trip characteristic and is part of the GHB Series, designed for bolt-on mounting in Eaton Powerline Panelboards.

Where to buy the EATON GHB3040 worldwide?

3G Electric supplies the EATON GHB3040 miniature circuit breaker worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this Eaton GHB Series breaker.

How to install the EATON GHB3040 miniature circuit breaker?

Install the EATON GHB3040 by bolting it into an Eaton Powerline Panelboard. Ensure the panel is de-energized, torque terminals to manufacturer specifications, and verify the 40 A rating matches the circuit load. Follow all applicable electrical codes and use proper personal protective equipment.
