EATON Molded Case Circuit Breaker: 3 A Amps, 65kA at 600V AC, Fixed, ABC, Line/Load Lug - Eaton Motor Circuit Protectors
EATONEaton Motor Circuit Protectors

EATON Molded Case Circuit Breaker: 3 A Amps, 65kA at 600V AC, Fixed, ABC, Line/Load Lug

The EATON HMCP003A0C is a 3 A molded case circuit breaker from the HMCP series of motor circuit protectors. It features a 250A/J frame size, a maximum AIR rating of 65kA at 600V AC, fixed instantaneous trip, ABC…

SKU 3G-OTH-23632

Brand
EATON
Item
Molded Case Circuit Breaker: 3 A Amps, 65kA at 600V AC, Fixed, ABC, Line/Load Lug
Category
Eaton Motor Circuit Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
HMCP003A0C
Series
HMCP
Type
65kA at 600V AC, Fixed, ABC, Line/Load Lug, Std, HMCP
Frame Size
250A/J
Max. AIR Rating
65kA at 600V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Line/Load Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON HMCP003A0C is a 3 A molded case circuit breaker from the HMCP series of motor circuit protectors. It features a 250A/J frame size, a maximum AIR rating of 65kA at 600V AC, fixed instantaneous trip, ABC phase connection, and line/load lug terminals.

Frequently Asked Questions

What is the EATON HMCP003A0C motor circuit protector used for?

The EATON HMCP003A0C is a 3 A molded case circuit breaker designed to protect motor circuits from short circuits and overloads. It is commonly used in industrial motor control applications, such as conveyors, pumps, and compressors, where reliable overcurrent protection is required.

What are the specifications of the EATON HMCP003A0C?

The EATON HMCP003A0C is a 3 A motor circuit protector from the HMCP series. It has a 250A/J frame size, a maximum AIR rating of 65kA at 600V AC, fixed instantaneous trip, ABC phase connection, and line/load lug terminals. The manufacturer part number is HMCP003A0C.

Where to buy the EATON HMCP003A0C worldwide?

You can source the EATON HMCP003A0C through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this motor circuit protector.

How to select the correct EATON HMCP motor circuit protector?

To select the correct EATON HMCP motor circuit protector, match the ampere rating (e.g., 3 A for HMCP003A0C) to the motor full-load current. Verify the frame size (250A/J), maximum AIR rating (65kA at 600V AC), and phase connection (ABC). Ensure terminals suit your wiring (line/load lug). Consult a qualified engineer for proper coordination.
