EATON Molded Case Circuit Breaker: 7 A Amps, 65kA at 600V AC, Fixed, ABC, Line/Load Lug - Eaton Motor Circuit Protectors
EATONEaton Motor Circuit Protectors

EATON Molded Case Circuit Breaker: 7 A Amps, 65kA at 600V AC, Fixed, ABC, Line/Load Lug

The EATON Molded Case Circuit Breaker (SKU 46MX99) is a motor circuit protector from the HMCP series with a 7 A amp rating. It features a 250A/J frame size, a maximum AIR rating of 65kA at 600V AC, fixed…

SKU 3G-OTH-23653

Brand
EATON
Item
Molded Case Circuit Breaker: 7 A Amps, 65kA at 600V AC, Fixed, ABC, Line/Load Lug
Category
Eaton Motor Circuit Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
HMCPS007C0C
Series
HMCP
Type
65kA at 600V AC, Fixed, ABC, Line/Load Lug, Std, HMCP
Frame Size
250A/J
Max. AIR Rating
65kA at 600V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Line/Load Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Molded Case Circuit Breaker (SKU 46MX99) is a motor circuit protector from the HMCP series with a 7 A amp rating. It features a 250A/J frame size, a maximum AIR rating of 65kA at 600V AC, fixed instantaneous trip, ABC phase connection, and line/lug terminal connections (MPN HMCPS007C0C).

Frequently Asked Questions

What is the EATON HMCP motor circuit protector used for?

The EATON HMCP motor circuit protector is used to protect motor branch circuits from short circuits and overloads. It is designed for industrial applications requiring a 7 A amp rating, fixed instantaneous trip, and ABC phase connection, ensuring reliable motor protection in panelboards and motor control centers.

What are the specifications of the EATON HMCP HMCPS007C0C?

The EATON HMCP HMCPS007C0C is a molded case circuit breaker with a 7 A amp rating, 250A/J frame size, and a maximum AIR rating of 65kA at 600V AC. It features fixed instantaneous trip, ABC phase connection, and line/lug terminal connections. It is part of the HMCP series from Eaton.

Where to buy the EATON HMCP motor circuit protector worldwide?

You can source the EATON HMCP motor circuit protector worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this Eaton motor circuit protector.

How to select the right EATON HMCP motor circuit protector?

To select the right EATON HMCP motor circuit protector, match the amp rating (e.g., 7 A) to your motor full-load current, ensure the frame size (250A/J) accommodates your system, and verify the AIR rating (65kA at 600V AC) exceeds available fault current. Confirm phase connection (ABC) and terminal type (line/lug) for your installation.
