EATON Molded Case Circuit Breaker: 200 A Amps, 25kA at 240V AC, Fixed, ABC, Line/Load Lug
The EATON JGE3200FAG is a JG-Frame Molded Case Circuit Breaker rated for 200 A with a 25kA interrupting capacity at 240V AC. It features a fixed trip unit, ABC phase protection, and line/load lug terminations. This…
SKU 3G-OTH-127698
Need installation or engineering help?
Ask a question
Product Description
The EATON JGE3200FAG is a JG-Frame Molded Case Circuit Breaker rated for 200 A with a 25kA interrupting capacity at 240V AC. It features a fixed trip unit, ABC phase protection, and line/load lug terminations. This unit is part of the JG frame series and is designed for standard industrial applications.
Frequently Asked Questions
What is the EATON JGE3200FAG molded case circuit breaker used for?
The EATON JGE3200FAG is a JG-frame molded case circuit breaker rated for 200 A with a 25kA interrupting capacity at 240V AC. It provides ABC phase protection and is designed for standard industrial applications such as motor control centers, panelboards, and distribution equipment.
What are the specifications of the EATON JGE3200FAG circuit breaker?
The EATON JGE3200FAG is a 200 A, JG-frame molded case circuit breaker with a 25kA interrupting capacity at 240V AC. It features a fixed trip unit, ABC phase protection, and line/load lug terminations. The unit is part of the JG series and is rated for 250A/JG frame size.
Where to buy the EATON JGE3200FAG circuit breaker worldwide?
3G Electric supplies the EATON JGE3200FAG molded case circuit breaker to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this JG-frame breaker.
How to select the right EATON molded case circuit breaker for an application?
To select the correct EATON molded case circuit breaker, match the continuous current rating (e.g., 200 A), interrupting capacity (e.g., 25kA at 240V AC), and trip unit type (fixed, ABC) to your system's voltage and fault current. Verify frame size (JG) and termination style (line/load lug) per your panel requirements.
Used in
Common applications for EATONEATON Products
3G Electric supplies EATON jg-frame eaton molded case circuit breakers. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
