EATON Plug-In Limit Switch: 29 mm Mounting Hole Vertical Center to Center Distance, 90°
The EATON E50BR1 is a roller lever-arm limit switch from the E50 Series, featuring a 29 mm mounting hole vertical center-to-center distance and a 90° lever-rod actuator. It uses screw terminals for electrical…
SKU 3G-OTH-31006
Need installation or engineering help?
Ask a question
Product Description
The EATON E50BR1 is a roller lever-arm limit switch from the E50 Series, featuring a 29 mm mounting hole vertical center-to-center distance and a 90° lever-rod actuator. It uses screw terminals for electrical connection and is designed as a plug-in limit switch for industrial applications.
Frequently Asked Questions
What is the EATON E50BR1 limit switch used for?
The EATON E50BR1 is a roller lever-arm limit switch used in industrial automation to detect the presence or position of moving machinery parts. Its 90° lever-rod actuator and plug-in design make it suitable for conveyor systems, packaging equipment, and material handling applications where reliable position sensing is required.
What are the specifications of the EATON E50BR1?
The EATON E50BR1 is a plug-in limit switch from the E50 Series with a 29 mm mounting hole vertical center-to-center distance and a 90° lever-rod actuator. It uses screw terminals for electrical connection and is designed for industrial environments requiring durable position sensing.
Where to buy the EATON E50BR1 worldwide?
You can source the EATON E50BR1 worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this E50 Series limit switch.
How to install the EATON E50BR1 limit switch?
Mount the EATON E50BR1 using the 29 mm vertical center-to-center holes, ensuring the lever-rod actuator aligns with the target. Connect wires to the screw terminals per your control circuit diagram. Test actuation by moving the roller lever through its 90° arc to confirm proper switching.
