EATON Plug-In Limit Switch: 29 mm Mounting Hole Vertical Center to Center Distance, 90°
The EATON E50BM1 is a plug-in limit switch from the E50 Series, featuring a roller lever-arm actuator with a 29 mm mounting hole vertical center-to-center distance and a 90° lever-rod. This industrial switch uses…
SKU 3G-OTH-31240
Need installation or engineering help?
Ask a question
Product Description
The EATON E50BM1 is a plug-in limit switch from the E50 Series, featuring a roller lever-arm actuator with a 29 mm mounting hole vertical center-to-center distance and a 90° lever-rod. This industrial switch uses screw terminals for electrical connection and is designed for reliable position sensing in automation and machinery applications.
Frequently Asked Questions
What is the EATON E50BM1 plug-in limit switch used for?
The EATON E50BM1 is a roller lever-arm limit switch used for position sensing in industrial automation and machinery. It detects the presence or absence of an object, triggering control circuits in conveyors, packaging equipment, and assembly lines. Its 90° lever-rod actuator provides reliable mechanical actuation in confined spaces.
What are the specifications of the EATON E50BM1 limit switch?
The EATON E50BM1 is a plug-in limit switch from the E50 Series. It features a roller lever-arm actuator with a 29 mm mounting hole vertical center-to-center distance and a 90° lever-rod. Electrical connection is via screw terminals. The manufacturer part number is E50BM1.
Where to buy the EATON E50BM1 limit switch worldwide?
You can source the EATON E50BM1 limit switch through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine EATON components for automation applications.
How to install the EATON E50BM1 plug-in limit switch?
Mount the EATON E50BM1 using the 29 mm vertical center-to-center holes, ensuring the roller lever-arm aligns with the cam or actuator. Connect wires to the screw terminals per the wiring diagram. Verify the 90° lever-rod moves freely without binding. Test actuation before energizing the circuit.
Used in
Common applications for EATONEATON Products
3G Electric supplies EATON roller lever-arm limit switches. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
