EATON Manual Motor Protector: Non-Reversing, 3 Poles, 25 A, Thermal Protection - Non-Reversing Starters with Thermal Overloads
EATONNon-Reversing Starters with Thermal Overloads

EATON Manual Motor Protector: Non-Reversing, 3 Poles, 25 A, Thermal Protection

The EATON Manual Motor Protector: Non-Reversing (MPN XTPB025BC1) is a non-reversing starter with integrated thermal overloads, featuring 3 poles, 25 A, and thermal protection via push-button operation. It has a…

SKU 3G-OTH-42584

Brand
EATON
Item
Manual Motor Protector: Non-Reversing, 3 Poles, 25 A, Thermal Protection
Category
Non-Reversing Starters with Thermal Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
XTPB025BC1
Type
25 A, Thermal Protection, Push Button
Poles
3
Frame Size (Width)
45mm (B Frame)
Maximum Voltage Rating
600V AC
Thermal Units Required
None (Starter Includes Integrated Thermal Units)
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Manual Motor Protector: Non-Reversing (MPN XTPB025BC1) is a non-reversing starter with integrated thermal overloads, featuring 3 poles, 25 A, and thermal protection via push-button operation. It has a maximum voltage rating of 600V AC and a 45mm (B Frame) width, with no additional thermal units required as the starter includes integrated thermal units.

Frequently Asked Questions

What is the EATON XTPB025BC1 manual motor protector used for?

The EATON XTPB025BC1 is a non-reversing manual motor protector used to start and stop motors while providing integrated thermal overload protection. It is commonly applied in industrial machinery, conveyors, and pumps where reliable motor control and protection against overloads are required.

What are the specifications of the EATON XTPB025BC1?

The EATON XTPB025BC1 is a 3-pole, non-reversing manual motor protector rated at 25 A with a maximum voltage of 600V AC. It features push-button operation and integrated thermal units, so no separate thermal units are needed. The frame size is 45mm (B Frame).

Where to buy the EATON XTPB025BC1 worldwide?

You can source the EATON XTPB025BC1 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine EATON components for industrial applications.

How to install the EATON XTPB025BC1 manual motor protector?

Mount the EATON XTPB025BC1 on a DIN rail or panel using the 45mm B frame. Connect the motor leads to the output terminals and the supply to the input terminals. Set the integrated thermal overload dial to match the motor full-load current. Test push-button operation before energizing.
