EATON Indicating Light: 22 mm Panel Mounting Size, Red, LED - LED Pilot-Lights
EATONLED Pilot-Lights

EATON Indicating Light: 22 mm Panel Mounting Size, Red, LED

The EATON M22-L-R-230R is a red LED pilot light from the M22 series, designed for 22 mm panel mounting. It operates with a maximum supply voltage rating of 264 V AC/DC and does not include a push-to-test feature.

SKU 3G-OTH-35933

Brand
EATON
Item
Indicating Light: 22 mm Panel Mounting Size, Red, LED
Category
LED Pilot-Lights
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
M22-L-R-230R
Series
M22
Type
Red, LED
Includes Push-To-Test
No Push-To-Test Included
AC/DC Max Volt Rating (Supply)
264 V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
