EATON Circuit Breaker: 50 A Amps, 65 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Circuit Breaker: 50 A Amps, 65 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT60, MPN PDG13M0050TFFJ) is a 50 A amp, 3-pole circuit breaker with a 125A/Frame 1 frame size. It features a fixed instantaneous trip, a maximum AIR rating…

SKU 3G-OTH-24685

Brand
EATON
Item
Circuit Breaker: 50 A Amps, 65 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG13M0050TFFJ
Type
65 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs, Std
Poles
3
Frame Size
125A/Frame 1
Max. AIR Rating
65 kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Standard Line and Load Lugs
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT60, MPN PDG13M0050TFFJ) is a 50 A amp, 3-pole circuit breaker with a 125A/Frame 1 frame size. It features a fixed instantaneous trip, a maximum AIR rating of 65 kA at 480V AC, and ABC phase connection. Terminal connection is via standard line and load lugs.

Frequently Asked Questions

What is the EATON Power Defense Molded Case Circuit Breaker used for?

The EATON Power Defense Molded Case Circuit Breaker is used for overcurrent protection in industrial and commercial electrical distribution systems. It safeguards circuits and equipment from damage due to overloads and short circuits, with a 50 A rating and 65 kA interrupting capacity at 480V AC.

What are the specifications of the EATON PDG13M0050TFFJ circuit breaker?

The EATON PDG13M0050TFFJ is a 3-pole, 50 A circuit breaker with a 125A/Frame 1 frame size. It has a maximum AIR rating of 65 kA at 480V AC, fixed instantaneous trip, ABC phase connection, and standard line and load lugs. It is part of the Power Defense series.

Where to buy the EATON PDG13M0050TFFJ circuit breaker worldwide?

You can source the EATON PDG13M0050TFFJ circuit breaker worldwide through 3G Electric. As a global industrial equipment distributor, 3G Electric handles full logistics, customs clearance, and delivery to your location, ensuring a seamless procurement process for this EATON Power Defense breaker.

How to select the correct EATON Power Defense circuit breaker for an application?

To select the correct EATON Power Defense circuit breaker, match the amp rating (e.g., 50 A), voltage (480V AC), and interrupting capacity (65 kA) to your system's requirements. Verify the frame size (125A/Frame 1), pole count (3), and trip type (fixed instantaneous). Consult a licensed electrician for proper coordination.
