EATON Circuit Breaker: 80 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Circuit Breaker: 80 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT93, MPN PDG22G0080TFFL) is an 80 A, 2-pole unit with a 225A/Frame 2 frame size. It features a maximum AIR rating of 35 kA at 480V AC, fixed instantaneous…

SKU 3G-OTH-23711

Brand
EATON
Item
Circuit Breaker: 80 A Amps, 35 kA at 480V AC, Fixed, AB, Std Terminals Load Only
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG22G0080TFFL
Type
35 kA at 480V AC, Fixed, AB, Std Terminals Load Only, Std
Poles
2
Frame Size
225A/Frame 2
Max. AIR Rating
35 kA at 480V AC
Phase Connection
AB
Instantaneous Trip
Fixed
Terminal Connection
Standard Terminals Load Only
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT93, MPN PDG22G0080TFFL) is an 80 A, 2-pole unit with a 225A/Frame 2 frame size. It features a maximum AIR rating of 35 kA at 480V AC, fixed instantaneous trip, AB phase connection, and standard terminals load only.

Frequently Asked Questions

What is the EATON Power Defense molded case circuit breaker used for?

The EATON Power Defense molded case circuit breaker (MPN PDG22G0080TFFL) protects electrical circuits from overloads and short circuits in industrial and commercial power distribution systems. It is suitable for applications requiring 80 A, 2-pole protection with a 35 kA interrupting rating at 480V AC.

What are the specifications of the EATON PDG22G0080TFFL circuit breaker?

This EATON circuit breaker is rated 80 A, 2-pole, with a 225A/Frame 2 frame size. It has a maximum AIR rating of 35 kA at 480V AC, fixed instantaneous trip, AB phase connection, and standard terminals load only. The manufacturer part number is PDG22G0080TFFL.

Where to buy the EATON PDG22G0080TFFL circuit breaker worldwide?

3G Electric supplies the EATON Power Defense circuit breaker (MPN PDG22G0080TFFL) to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this 80 A, 2-pole unit.

How to select the correct EATON molded case circuit breaker for your application?

To select the correct EATON molded case circuit breaker, verify your system voltage (e.g., 480V AC), required amp rating (80 A), number of poles (2), and interrupting capacity (35 kA). Ensure the frame size (225A/Frame 2) and terminal type (standard terminals load only) match your panel and wiring configuration.
