EATON Circuit Breaker: 20 A Amps, 25 kA at 480V AC, Fixed, ABC, Std Terminals Load Only - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Circuit Breaker: 20 A Amps, 25 kA at 480V AC, Fixed, ABC, Std Terminals Load Only

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT97, MPN PDG23F0020TFFL) is a 20 A rated device with a 225A/Frame 2 frame size. It features a maximum AIR rating of 25 kA at 480V AC, a fixed instantaneous…

SKU 3G-OTH-24748

Brand
EATON
Item
Circuit Breaker: 20 A Amps, 25 kA at 480V AC, Fixed, ABC, Std Terminals Load Only
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG23F0020TFFL
Type
25 kA at 480V AC, Fixed, ABC, Std Terminals Load Only, Std
Frame Size
225A/Frame 2
Max. AIR Rating
25 kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Standard Terminals Load Only
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HT97, MPN PDG23F0020TFFL) is a 20 A rated device with a 225A/Frame 2 frame size. It features a maximum AIR rating of 25 kA at 480V AC, a fixed instantaneous trip, and ABC phase connection. The unit includes standard terminals for load-only connection.

Frequently Asked Questions

What is the EATON Power Defense molded case circuit breaker used for?

The EATON Power Defense molded case circuit breaker (MPN PDG23F0020TFFL) protects electrical circuits from overloads and short circuits in industrial and commercial power distribution systems. Its 20 A rating and 25 kA interrupting capacity at 480V AC suit motor control centers, panelboards, and switchboards.

What are the specifications of the EATON PDG23F0020TFFL circuit breaker?

This EATON Power Defense breaker is rated 20 A with a 225A/Frame 2 frame size. It has a maximum AIR rating of 25 kA at 480V AC, fixed instantaneous trip, ABC phase connection, and standard terminals for load-only connection. The part number is PDG23F0020TFFL.

Where to buy the EATON PDG23F0020TFFL circuit breaker worldwide?

3G Electric supplies the EATON Power Defense PDG23F0020TFFL circuit breaker to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this breaker.

How to select the correct EATON molded case circuit breaker for your application?

Select an EATON MCCB by matching the continuous current rating (e.g., 20 A), interrupting capacity (e.g., 25 kA at 480V AC), frame size (e.g., 225A/Frame 2), and trip type (fixed instantaneous) to your system's voltage and fault current. Verify phase connection (ABC) and terminal configuration (load-only) per your panel design.
