EATON Circuit Breaker: 40 A Amps, 35 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs - Power Defense Molded Case Circuit Breakers
EATONPower Defense Molded Case Circuit Breakers

EATON Circuit Breaker: 40 A Amps, 35 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HU65, MPN PDG13G0040TFFJ) is a 40 A, 3-pole unit with a 125A/Frame 1 frame size. It features a fixed instantaneous trip, a maximum AIR rating of 35 kA at…

SKU 3G-OTH-24128

Brand
EATON
Item
Circuit Breaker: 40 A Amps, 35 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs
Category
Power Defense Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
PDG13G0040TFFJ
Type
35 kA at 480V AC, Fixed, ABC, Std Line and Load Lugs, Std
Poles
3
Frame Size
125A/Frame 1
Max. AIR Rating
35 kA at 480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Standard Line and Load Lugs
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Power Defense Molded Case Circuit Breaker (SKU 61HU65, MPN PDG13G0040TFFJ) is a 40 A, 3-pole unit with a 125A/Frame 1 frame size. It features a fixed instantaneous trip, a maximum AIR rating of 35 kA at 480V AC, and ABC phase connection. The breaker includes standard line and load lugs for terminal connection.

Frequently Asked Questions

What is the EATON Power Defense molded case circuit breaker used for?

The EATON Power Defense molded case circuit breaker is used for overcurrent protection in industrial and commercial electrical distribution systems. It safeguards branch circuits, feeders, and equipment against short circuits and overloads, with a 40 A rating and 35 kA interrupting capacity at 480V AC.

What are the specifications of the EATON PDG13G0040TFFJ circuit breaker?

The EATON PDG13G0040TFFJ is a 3-pole, 40 A Power Defense molded case circuit breaker with a 125A/Frame 1 frame size. It has a maximum AIR rating of 35 kA at 480V AC, fixed instantaneous trip, ABC phase connection, and standard line and load lugs for terminal connection.

Where to buy the EATON PDG13G0040TFFJ circuit breaker worldwide?

You can source the EATON PDG13G0040TFFJ circuit breaker through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring you receive genuine EATON Power Defense breakers for your projects.

How to select the correct EATON Power Defense circuit breaker for my application?

To select the correct EATON Power Defense breaker, match the continuous current rating (e.g., 40 A) to your load, verify the interrupting capacity (35 kA at 480V AC) exceeds available fault current, and confirm the frame size (125A/Frame 1) accommodates your wiring. Consult a licensed engineer for coordination studies.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas

EATON Products

3G Electric supplies EATON power defense molded case circuit breakers. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
