EATON Overload Relay: Electronic Protection, 3 Poles, NEMA Size 00 - NEMA Electronic Overload Relays
EATONNEMA Electronic Overload Relays

EATON Overload Relay: Electronic Protection, 3 Poles, NEMA Size 00

The EATON Overload Relay: Electronic Protection is a NEMA electronic overload relay with three poles and NEMA Size 00, rated for 0.33 A – 1.65 A and a maximum voltage of 690V AC. It features screw clamp terminals and…

SKU 3G-OTH-41539

Brand
EATON
Item
Overload Relay: Electronic Protection, 3 Poles, NEMA Size 00
Category
NEMA Electronic Overload Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
C440A1A1P6SF00
Type
NEMA Size 00, 0.33 A – 1.65 A
Phase
Three
Poles
3
Maximum Voltage Rating
690V AC
Thermal Units Required
Not Applicable to Electronic Type Overload Relays
Terminal Connection Type
Screw Clamp Terminals
Compatible Contactor Series
C25 Definite Purpose
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Overload Relay: Electronic Protection is a NEMA electronic overload relay with three poles and NEMA Size 00, rated for 0.33 A – 1.65 A and a maximum voltage of 690V AC. It features screw clamp terminals and is compatible with the C25 Definite Purpose contactor series. This three-phase device does not require thermal units, as it is an electronic type overload relay.

Frequently Asked Questions

What is the EATON C440A1A1P6SF00 overload relay used for?

The EATON C440A1A1P6SF00 is an electronic overload relay used to protect three-phase motors from overloads and phase loss. It is designed for NEMA Size 00 applications and integrates with the C25 Definite Purpose contactor series, making it suitable for industrial motor control panels and HVAC equipment.

What are the specifications of the EATON C440A1A1P6SF00 overload relay?

The EATON C440A1A1P6SF00 is a three-pole NEMA electronic overload relay rated for 0.33 A to 1.65 A with a maximum voltage of 690V AC. It uses screw clamp terminals, is compatible with the C25 Definite Purpose contactor series, and requires no thermal units due to its electronic design.

Where to buy the EATON C440A1A1P6SF00 overload relay worldwide?

3G Electric supplies the EATON C440A1A1P6SF00 overload relay worldwide. As a global industrial equipment distributor established in 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the correct EATON overload relay for a motor?

To select the correct EATON overload relay, match the relay's current range (e.g., 0.33 A – 1.65 A for the C440A1A1P6SF00) to the motor's full-load amperage. Ensure the relay's voltage rating (690V AC) and pole count (three) match your system, and verify compatibility with your contactor series, such as the C25 Definite Purpose.
